| Expand All | ||||
|---|---|---|---|---|
| Weights and Measures | ||||
| Dimensions | ||||
| Overall Length (approx.)1 | 25' 8" | 25' 8" | ||
| Wheel Base | 170.3" | 170.3" | ||
| Overall Width2 | 90" | 90" | ||
| Overall Height | 11' 4" | 11' 4" | ||
| Interior Height3 | 86" | 86" | ||
| Interior Width | 87" | 87" | ||
| Basement Storage (cubic feet, approx.) | 130 | 54 | ||
| Square Footage (approx.) | 146 | 164 | ||
| 1The approximated coach width and length does not include side-view mirrors. | ||||
| 2The approximated coach width and length does not include side-view mirrors. | ||||
| 3Mid-Year: Change to 86" | ||||
| Weight Limits | ||||
| GAWR-Front (pounds) | 4410 | 4410 | ||
| GAWR-Rear (pounds) | 7720 | 7720 | ||
| GVWR (pounds) | 11030 | 11030 | ||
| Hitch Rating (pounds)4 | 5000 | 5000 | ||
| GCWR (pounds) | 15250 | 15250 | ||
| 4Tow ratings and ability are subject to gross combined weight ratings on the tow vehicle. Hitch rated at 500-pound vertical tongue weight and includes 7-pin connector. | ||||
| Capacities | ||||
| Fuel Tank (gallons) | 24.5 | 24.5 | ||
| DEF Tank (gallons)5 | 4.8 | 4.8 | ||
| Fresh Water (gallons) | 32 | 32 | ||
| Grey Water (gallons) | 32 | 32 | ||
| Black Water (gallons) | 28 | 28 | ||
| LPG Tank (gallons) | 12 | 12 | ||
| 5Diesel Exhaust Fluid (DEF) is the active component used in Selective Catalytic Reduction (SCR) engines to reduce nitrogen oxide emissions by 90% to meet EPA standards. | ||||
| Quantities | ||||
| Number of Slideouts | 1 | 1 | ||
| Sleeping Capacity6 | 2 to 4 | 2 to 4 | ||
| Sleeping Areas7 | 2 to 4 | 1 to 3 | ||
| Seat Belts8 | 4 | 4 | ||
| Seating Capacity9 | 4 | 4 | ||
| 6Dependent on furniture and dinette options. | ||||
| 7Dependent on furniture and dinette options. | ||||
| 8Dependent on furniture and dinette options. | ||||
| 9Dependent on furniture and dinette options. | ||||
| Chassis and Drivetrain | ||||
| Chassis and Drivetrain Features | ||||
| Mercedes-Benz® 3500XD Dual Wheel Cutaway Chassis | STD | STD | ||
| Mercedes-Benz® 2.0 Liter I4 Turbo Diesel High Output 208 HP Diesel Engine with 332 lb-ft Torque | STD | STD | ||
| Two-wheel Drive | STD | STD | ||
| 220-Amp Alternator | STD | STD | ||
| Mercedes-Benz® 9G-Tronic Automatic Transmission | STD | STD | ||
| Aluminum Wheels | STD | STD | ||
| Front and Rear LT 215/85R 16 Tires | STD | STD | ||
| (1) 12-Volt Flooded Lead-Acid Chassis Batteries | STD | STD | ||
| Lippert Hydraulic Leveling System with Control Panel | STD | STD | ||
| SumoSprings® Ride Assist System | STD | STD | ||
| Front Radiator | STD | STD | ||
| Four Wheel ABS Brakes | STD | STD | ||
| Manual Parking Brake | STD | STD | ||
| Active Brake Assist (Collision Mitigation) | STD | STD | ||
| Active Distance Assist Distronic® (Adaptive Cruise Control) | STD | STD | ||
| Attention Assist | STD | STD | ||
| Traffic Sign Assist | STD | STD | ||
| Load Adaptive Electronic Stability Program (ESP) | STD | STD | ||
| High Beam Assist | STD | STD | ||
| Active Lane Keeping Assist | STD | STD | ||
| Construction | ||||
| Construction Features | ||||
| Seamless One-piece Gel-coat Fiberglass Molded Roof Cap | STD | STD | ||
| One-piece Molded Gel-coat Fiberglass Front and Rear Caps | STD | STD | ||
| Electrical | ||||
| Electrical Features | ||||
| Spyder Controls Multiplex System | STD | STD | ||
| Firefly Integrations Mira Module10 | STD | STD | ||
| Interior Entryway Spyder System Main Monitor | STD | STD | ||
| Additional Spyder System Switch Panel | STD | STD | ||
| (1) 15,000-BTU Air Conditioner with Heat Pump | STD | STD | ||
| Wall-mounted Thermostat with Built-in Temperature Sensor | STD | STD | ||
| SmartPlug® Detachable 30-Amp Shore Power Cord | STD | STD | ||
| Prep for 2 Solar Panels11 | STD | STD | ||
| HD Over-the-air Antenna | STD | STD | ||
| Park Cable and Ground Satellite Hook-up | STD | STD | ||
| Prep for In-motion Satellite | STD | STD | ||
| HDMI Ports | STD | STD | ||
| Mercedes-Benz® Wireless Internet Access | STD | STD | ||
| 12-Volt Breaker Panel | STD | STD | ||
| 12-Volt Disconnect Switch | STD | STD | ||
| Inverted Outlets for CPAP Machine in Bedroom | STD | STD | ||
| Ground Fault Circuit Interrupter (GFCI) Outlets at Galley, Lavatories, and Sewer Bay | STD | STD | ||
| 110-Volt Exterior Receptacle | STD | STD | ||
| Surge Guard® Transfer Switch | STD | STD | ||
| USB Receptacles Throughout Coach | STD | STD | ||
| 10Download the accompanying Vegatouch app to control your coach locally within Bluetooth range. | ||||
| 11Includes a docking port for an aftermarket solar panel. | ||||
| Heating and Cooktop Power Source | ||||
| Liquid Propane (LP) Coach12 | STD | STD | ||
| Hydronic Heating & Electronic Appliance Equipped Coach13 | OPT | OPT | ||
| 12Propane is used to power the ducted furnaces, the water heater, and the liquid propane cooktop. | ||||
| 13This option utilizes a hydronic heating system, an induction cooktop, and a 12V refrigerator. These systems replace the ducted furnaces, the Truma AquaGo water heater, the liquid propane cooktop, and the gas electric refrigerator. | ||||
| Generators and Power Systems | ||||
| 4-Kilowatt RVMP Flex Power LP Generator | STD | STD | ||
| 2,000-Watt Pure Sine Wave Inverter | STD | STD | ||
| House Batteries | ||||
| (2) 12-Volt Flooded Lead-Acid House Batteries14 | STD | STD | ||
| (2) 12-Volt Lithium House Battery15 | OPT | OPT | ||
| 14House batteries are stored under the entry steps. | ||||
| 15House batteries are stored under the entry steps. | ||||
| Space Heating | ||||
| (1) 30,000-BTU Ducted Furnace | DEP | DEP | ||
| Hydronic Heating System16 | DEP | DEP | ||
| 16Replaces ducted furnaces when hydronic heating & electronic appliance equipped coach option is selected. A Hydronic Heating System provides both heated air and water. | ||||
| Electrical Add On Options | ||||
| (1) 200-Watt Solar Panel with (1) 30-Amp Controller | OPT | OPT | ||
| Starlink Pro | OPT | OPT | ||
| Wi-Fi Booster | OPT | OPT | ||
| Plumbing | ||||
| Plumbing Features | ||||
| Water Heater Bypass System | STD | STD | ||
| Aqua View Showermiser™ | STD | STD | ||
| Water Filter | STD | STD | ||
| Water Pump | STD | STD | ||
| Low-point Water Drain Lines | STD | STD | ||
| Black Holding Tank Flush System | STD | STD | ||
| Gravity Water Fill | STD | STD | ||
| Heated Fresh and Holding Tanks via Tank Pads and Heat Duct | STD | STD | ||
| Tank Level Monitor System | STD | STD | ||
| Centralized Exterior Sewer Bay with Gravity Black and Grey Evacuation Ports | STD | STD | ||
| Exterior Rinse Hose with Shower Head | STD | STD | ||
| Fresh Water Hookup for City Water and Tank Fill | STD | STD | ||
| Sewer Hose Storage | STD | STD | ||
| Water Heater Options | ||||
| Truma AquaGo™ Comfort Plus Instant Water Heater17 | STD | STD | ||
| Hydronic Heating System18 | DEP | DEP | ||
| 17Only available with standard LP coach. | ||||
| 18Replaces Truma AquaGo™ Comfort Plus instant water heater when hydronic heating & electronic appliance equipped coach option is selected. A hydronic heating system provides both heated air and water. | ||||
| Exterior | ||||
| Exterior Features | ||||
| Full-body Paint with (2) Layers of Clear Coat | STD | STD | ||
| High Performance Protective Film on Front Cap, Front Cab, and Other Select Areas | STD | STD | ||
| (1) Girard® Side-mounted Powered Patio Awning with Integrated LED Lighting and Built-in Speakers | STD | STD | ||
| Lockable Handles on Compartment Doors | STD | STD | ||
| Motion-sensor Lights in Cargo Bay | STD | STD | ||
| Flush-Style Tinted Windows with Tip-out Feature | STD | STD | ||
| Exterior Patio Light | STD | STD | ||
| Fog Lights | STD | STD | ||
| Driver and Passenger Side Front Cap Exterior Entry Light | STD | STD | ||
| Heated, Electrically Adjustable Side-view Mirrors | STD | STD | ||
| Lightweight Entry Door | STD | STD | ||
| Entry Door Grab Handle | STD | STD | ||
| Mud Flaps | STD | STD | ||
| Exterior Add On Options | ||||
| Exterior TV | OPT | OPT | ||
| Paint Scheme Options | ||||
| Generation 7 Exterior Paint Scheme | OPT | OPT | ||
| Paint Color Options | ||||
| Coastal Blue Full Body Paint | OPT | OPT | ||
| Silver Sand Full Body Paint | OPT | OPT | ||
| Sea Mist Full Body Paint | OPT | OPT | ||
| Interior | ||||
| Interior Features | ||||
| High Pressure Laminate Cabinets19 | STD | STD | ||
| Steel Step Well with Composite Steps | STD | STD | ||
| Solid Surface Galley Countertop | STD | STD | ||
| Handcrafted Slide-out Fascia | STD | STD | ||
| Soft Touch Vinyl Ceiling | STD | STD | ||
| Dimmable LED Lighting | STD | STD | ||
| Accent Lighting in Lounge, Galley, and Bedroom | STD | STD | ||
| Carbon Monoxide Detector | STD | STD | ||
| LPG Leak Detector | STD | STD | ||
| Smoke Detector | STD | STD | ||
| Fire Extinguisher | STD | STD | ||
| Solar and Privacy Shades | STD | STD | ||
| Soft-closing Drawers | STD | STD | ||
| Powered Roof Vents | STD | STD | ||
| Interior Grab Handle at Entry Door | STD | STD | ||
| Stereo System with Separate Speaker Zones | STD | STD | ||
| (2) Captain’s Chair Lounge Cushions | STD | STD | ||
| 19Mid-Year change to Genesis | ||||
| Interior Décor Packages | ||||
| Sedona | OPT | OPT | ||
| Grandview | OPT | OPT | ||
| Upholstery Fabrics | ||||
| Franklin Snowhill Dove20 | DEP | DEP | ||
| Franklin Snownill Sand21 | DEP | DEP | ||
| 20Always paired with Sedona interior décor package. | ||||
| 21Always paired with Grandview interior décor package. | ||||
| Cabinetry Color | ||||
| Glistening Trail with Winter White Accent22 | OPT | OPT | ||
| Phantom Ecru with Winter White Accent23 | OPT | OPT | ||
| 22Mid-Year: Replace with Phantom Ecru | ||||
| 23Mid-Year: Replace with Glistening Trail | ||||
| Floor Tiles | ||||
| Stony Ground | STD | STD | ||
| Television | ||||
| Living Area Mounted TV24 | DEP | DEP | ||
| Bedroom TV | OPT | OPT | ||
| Overhead Bunk TV25 | DEP | DEP | ||
| 24On 25 RW and 25 LW, TV is over galley unless Overhead Entertain Center option is selected. | ||||
| 25Included with Overhead Entertainment Center option. | ||||
| Interior Add On Options | ||||
| Central Vacuum System | OPT | OPT | ||
| Driver's Compartment | ||||
| Driver's Compartment Features | ||||
| Adjustable Driver and Passenger Seats | STD | STD | ||
| Swivel Bases for Driver and Passenger Seats | STD | STD | ||
| Heated Driver and Passenger Seats | STD | STD | ||
| Leather Wrapped Steering Wheel with Integrated Controls | STD | STD | ||
| Keyless Start | STD | STD | ||
| Windshield with Filter Band | STD | STD | ||
| Rain Sensor for Windshield Wipers | STD | STD | ||
| Automatic LED Headlights | STD | STD | ||
| Emergency Call System | STD | STD | ||
| Smartphone Integration For Apple Carplay® and Android™ Auto | STD | STD | ||
| Mercedes-Benz® MBUX Multimedia System with 10.25” Touchscreen | STD | STD | ||
| Ceiling Mounted Speakers | STD | STD | ||
| Tray for Smartphones with Charging Ports | STD | STD | ||
| Intelligent Navigation | STD | STD | ||
| Auxiliary Start Switch | STD | STD | ||
| Powered Windows | STD | STD | ||
| Door-mounted Driver and Passenger Assist Handles | STD | STD | ||
| Powered Door Locks | STD | STD | ||
| Vinyl Floor Covering | STD | STD | ||
| Driver, Passenger, and Windshield Thermal Barrier Shades | STD | STD | ||
| Instrument Cluster with Color Display | STD | STD | ||
| Driver's Compartment Add On Options | ||||
| Side-view Cameras | OPT | OPT | ||
| Overhead Features | ||||
| Front Overhead Bunk | STD | STD | ||
| Overhead Entertainment Center26 | OPT | OPT | ||
| Cab Skylight27 | OPT | OPT | ||
| 26Replaces front TV over galley. Not combinable with cab skylight option. | ||||
| 27Not combinable with overhead entertainment center option. | ||||
| Dinette and Living Area | ||||
| Driver Side | ||||
| 52" Tri-fold Sofa Bed28 | STD | - | ||
| 50" Theater Seating | OPT | - | ||
| 72" Booth Dinette-Sleeper29 | - | STD | ||
| 68" Theater Seating | - | OPT | ||
| 70" Tri-fold Sofa Bed | - | OPT | ||
| Driver Side Queen-sized Murphy Bed (60" x 74") with Sofa30 | - | STD | ||
| 28Piece of furniture sleeps one comfortably. | ||||
| 29Piece of furniture sleeps one comfortably. | ||||
| 30Piece of furniture sleeps two comfortably. | ||||
| Kitchen | ||||
| Kitchen Features | ||||
| Stainless Steel Convection Microwave | STD | STD | ||
| Stainless Steel Single Bowl Sink and Faucet with Built-in Sprayer | STD | STD | ||
| Galley Overhead Cabinets | STD | STD | ||
| Sliding Countertop Extension within Drawer | STD | STD | ||
| Task Lighting | STD | STD | ||
| Solid Surface Galley Countertop | STD | STD | ||
| Refrigerator | ||||
| 12-Volt, 8-Cubic Foot Refrigerator31 | - | DEP | ||
| Gas-Electric, 7-Cubic Foot Refrigerator32 | - | DEP | ||
| 12-Volt, 5.3-Cubic Foot Refrigerator33 | DEP | - | ||
| Gas-Electric, 5-Cubic Foot Refrigerator34 | DEP | - | ||
| 31Required with hydronic heating & electronic appliance equipped coach option. | ||||
| 32Required with LP coach option. | ||||
| 33Required with hydronic heating & electronic appliance equipped coach option. | ||||
| 34Required with LP coach option. | ||||
| Cooking Appliances | ||||
| One-Burner Induction Cooktop35 | DEP | DEP | ||
| Liquid Propane Cooktop with Built-in Cover36 | DEP | DEP | ||
| 35Replaces liquid propane cooktop when hydronic heating & electronic appliance equipped coach option is selected. | ||||
| 36Only available with LP coach option. Not available with hydronic heating & electronic appliance equipped coach option. | ||||
| Bedroom | ||||
| Bedroom Features | ||||
| LED Reading Lights | STD | STD | ||
| Overhead Cabinets | STD | STD | ||
| Wardrobe | STD | STD | ||
| Mattress Options | ||||
| Queen-sized Murphy Bed (60" x 74") | - | STD | ||
| (2) Twin Mattresses (32" x 76"), Combines into King Bed (86" x 76")37 | STD | - | ||
| 3725 LW's twin mattresses can now combine into a king-sized bed. | ||||
| Bedroom Add On Options | ||||
| Sleeping Area Privacy Curtain | - | STD | ||
| Mounted Bedroom TV | OPT | OPT | ||
| Bedroom Storage | ||||
| Pop-up Closet Storage | STD | - | ||
| Closet Pull-out | STD | - | ||
| Bathroom | ||||
| Bathroom Features | ||||
| Porcelain Vessel Sink with Chrome Faucet38 | STD | STD | ||
| Handheld Shower Head | STD | STD | ||
| Shower Skylight | STD | STD | ||
| Towel and Toilet Paper Holders | STD | STD | ||
| Roof Vent Fan | STD | STD | ||
| Oversized Mirror | STD | STD | ||
| Base Cabinet | STD | STD | ||
| 38Mid-Year/PW: change Black Matte to Chrome | ||||
| Shower Options | ||||
| One-Piece Molded Fiberglass Shower (30" x 36") | - | STD | ||
| One-Piece Molded Fiberglass Shower (24" x 32") | STD | - | ||
