| Expand All | ||||
|---|---|---|---|---|
| Weights and Measures | ||||
| Dimensions | ||||
| Overall Length (approx.)1 | 25' 6" | |||
| Wheel Base | 170.3" | |||
| Overall Width2 | 84" | |||
| Overall Height | 11' 2" | |||
| Interior Height | 80" | |||
| Interior Width | 80.25" | |||
| Basement Storage (cubic feet, approx.) | 90 | |||
| Square Footage (approx.) | 114 | |||
| 1The approximated coach width and length does not include side-view mirrors. | ||||
| 2The approximated coach width and length does not include side-view mirrors. | ||||
| Weight Limits | ||||
| GAWR-Front (pounds) | 4410 | |||
| GAWR-Rear (pounds) | 7720 | |||
| GVWR (pounds) | 11030 | |||
| Hitch Rating (pounds)3 | 5000 | |||
| GCWR (pounds) | 15250 | |||
| 3Tow ratings and ability are subject to gross combined weight ratings on the tow vehicle. Hitch rated at 500-pound vertical tongue weight and includes 7-pin connector. | ||||
| Capacities | ||||
| Fuel Tank (gallons) | 24.5 | |||
| DEF Tank (gallons)4 | 4.8 | |||
| Fresh Water (gallons) | 52 | |||
| Grey Water (gallons) | 52 | |||
| Black Water (gallons) | 4.5 | |||
| LPG Tank (gallons) | - | |||
| 4Diesel Exhaust Fluid (DEF) is the active component used in Selective Catalytic Reduction (SCR) engines to reduce nitrogen oxide emissions by 90% to meet EPA standards. | ||||
| Quantities | ||||
| Number of Slideouts | 0 | |||
| Sleeping Capacity | 3 | |||
| Sleeping Areas | 2 | |||
| Seat Belts | 4 | |||
| Seating Capacity | 4 | |||
| Chassis and Drivetrain | ||||
| Chassis and Drivetrain Features | ||||
| Mercedes-Benz® 3500XD AWD Dual Wheel Cutaway Chassis | STD | |||
| Mercedes-Benz® 2.0 Liter I4 Turbo Diesel High Output 208 HP Diesel Engine with 332 lb-ft Torque | STD | |||
| All-wheel Drive | STD | |||
| 220-Amp Alternator | STD | |||
| Mercedes-Benz® 9G-Tronic Automatic Transmission | STD | |||
| Custom Tiffin Adventure Black Alloy Wheels | STD | |||
| Front and Rear LT 245/70R 16 Tires | STD | |||
| (1) 12-Volt Flooded Lead-Acid Chassis Batteries | STD | |||
| Premium Mercedes Driver & Passenger Seats with Electrical Controls | STD | |||
| Heated Driver & Passenger Seats | STD | |||
| Sumo Springs (Rear)5 | STD | |||
| Front Radiator | STD | |||
| Four Wheel ABS Brakes | STD | |||
| Manual Parking Brake | STD | |||
| Active Brake Assist (Collision Mitigation) | STD | |||
| Active Distance Assist Distronic® (Adaptive Cruise Control) | STD | |||
| Attention Assist | STD | |||
| Traffic Sign Assist | STD | |||
| Load Adaptive Electronic Stability Program (ESP) | STD | |||
| High Beam Assist | STD | |||
| Active Lane Keeping Assist | STD | |||
| 5These are removed if the Agile RIP Kit is installed | ||||
| Chassis and Drivetrain Add On Options | ||||
| Side View Cameras6 | OPT | |||
| Agile Offroad RIP Kit Suspension Upgrade | OPT | |||
| 6Shows blind spot camera in main MB dash when turn signals engaged | ||||
| Construction | ||||
| Construction Features | ||||
| Seamless One-piece Gel-coat Fiberglass Molded Roof Cap | STD | |||
| One-piece Molded Gel-coat Fiberglass Front and Rear Caps | STD | |||
| Electrical | ||||
| Electrical Features | ||||
| Spyder Controls Multiplex System | STD | |||
| Firefly Integrations Mira Module7 | STD | |||
| Interior Entryway Spyder System Main Monitor | STD | |||
| Additional Spyder System Switch Panel8 | STD | |||
| (1) 15,000-BTU Gree Air Conditioner with Heat Pump, Soft Start, & Variable Speed Compressor | STD | |||
| 3000W Xantrex Inverter | STD | |||
| Wall-mounted Thermostat with Built-in Temperature Sensor | STD | |||
| SmartPlug® Detachable 30-Amp Shore Power Cord | STD | |||
| Prep for 2 Solar Panels (Includes 30 Amp Solar Controller)9 | STD | |||
| Prep for Wolfbox Always-on Rearview Camera | STD | |||
| HD Over-the-air Antenna | STD | |||
| Park Cable and Ground Satellite Hook-up | STD | |||
| Prep for Starlink Mini | STD | |||
| Hydronic Heating | STD | |||
| Showermiser Hot Water Recirculation | STD | |||
| Mercedes-Benz® Wireless Internet Access | STD | |||
| 12-Volt Breaker Panel | STD | |||
| 12-Volt Disconnect Switch | STD | |||
| Outlets for CPAP Machine in Bedroom | STD | |||
| Ground Fault Circuit Interrupter (GFCI) Outlets at Galley, Lavatories, and Sewer Bay | STD | |||
| 110-Volt Exterior Receptacle | STD | |||
| USB & USB-C Receptacles Throughout Coach | STD | |||
| 7Download the accompanying Vegatouch app to control your coach locally within Bluetooth range. | ||||
| 8Located near bedroom | ||||
| 9Includes a docking port for an aftermarket solar panel. | ||||
| Generators and Power Systems | ||||
| 3.2-Kilowatt RVMP Diesel Generator & 270 AH (3,456 WH) Battleborn Lithium Battery Pack | STD | |||
| House Batteries | ||||
| 51V 165AH (8,448 WH) Lithionics Battery System10 | OPT | |||
| 10This swaps the 280-Amp secondary alternator out with the Lithionics alternator designed to work with their system | ||||
| Electrical Add On Options | ||||
| 2x 200W Solar Panels (400W) | OPT | |||
| Starlink Mini | OPT | |||
| Plumbing | ||||
| Plumbing Features | ||||
| Aqua View Showermiser™ | STD | |||
| Hydronic Hot Water Heater | STD | |||
| Water Filter | STD | |||
| Water Pump | STD | |||
| 4.5 Gallon Thetford C220 Indexable Cassette Toilet | STD | |||
| Low-point Water Drain Lines | STD | |||
| Gravity Water Fill | STD | |||
| Heated Water Tanks | STD | |||
| Tank Level Monitor System | STD | |||
| Centralized Exterior Sewer Bay with Gravity Grey Evacuation Ports | STD | |||
| Prepped For 45 Gallon Fuel Tank Upgrade | STD | |||
| Exterior Rinse Hose with Shower Head | STD | |||
| Fresh Water Hookup for City Water and Tank Fill | STD | |||
| Sewer Hose Storage | STD | |||
| Plumbing Add On Options | ||||
| Black Tank Toilet (Changes 52 Gallon Grey Tank to 26 Gallon Grey / 26 Gallon Black) | OPT | |||
| Exterior | ||||
| Exterior Features | ||||
| Full-body Paint with (2) Layers of Clear Coat | STD | |||
| Rugged Texturized Protective Coating On Lower Panels | STD | |||
| High Performance Diamondshield Protective Film on Front Cap, Front Cab, and Other Select Areas | STD | |||
| (1) Girard® Side-mounted Powered Patio Awning with Integrated LED Lighting and Built-in Speakers | STD | |||
| Exterior Running Boards | STD | |||
| Electric Entry Step | STD | |||
| Heavy Duty Offroad Front Bumper | STD | |||
| Black Powder Coated Aluminum Roof Rack | STD | |||
| Lockable Handles on Compartment Doors | STD | |||
| Motion-sensor Lights in Cargo Bay | STD | |||
| Nomadic Ark Argon-Filled Dual-Pane Insulated Acryllic Exterior Windows | STD | |||
| Exterior Patio Light | STD | |||
| Fog Lights | STD | |||
| Driver and Passenger Side Front Cap Exterior Entry Light | STD | |||
| Heated, Electrically Adjustable Side-view Mirrors | STD | |||
| Bear-Resistant Exterior Entry Door With All-Aluminum Construct | STD | |||
| Bear-Resistant Steel Interior Door with Airflow Screens and Heavy-Duty Drop-Bolt | STD | |||
| Riveted All-Aluminum Body Molding | STD | |||
| Custom Fabricated Aluminum Wheel Wells Sized For Super Single Wheels | STD | |||
| Exterior Add On Options | ||||
| Manual 270 Degree Batwing Awning | OPT | |||
| Exterior Paint Color Options | ||||
| Desert Tan Full Body Paint Scheme | OPT | |||
| Cement Grey Full Body Paint Scheme | OPT | |||
| Interior | ||||
| Interior Features | ||||
| Black Powder Coated Aluminum Cabinetry Throughout | STD | |||
| Aluminum-Framed Step Well With Composite Trim | STD | |||
| Dedicated Over-Cab Storage | STD | |||
| Solid Surface Galley Countertop w/Countertop Extension | STD | |||
| Stainless Steel Sink w/Hide-away faucet | STD | |||
| Soft Touch Vinyl Ceiling | STD | |||
| Dimmable LED Lighting | STD | |||
| Carbon Monoxide Detector | STD | |||
| LPG Leak Detector | STD | |||
| Smoke Detector | STD | |||
| Fire Extinguisher | STD | |||
| Solar and Privacy Shades | STD | |||
| Soft-closing Drawers | STD | |||
| Interior Grab Handle at Entry Door | STD | |||
| Interior Décor Packages | ||||
| Boho Chic | OPT | |||
| Cabinetry Color | ||||
| Matte Black Noir w/ Phantom Ecru Fronts | OPT | |||
| Driver's Compartment | ||||
| Driver's Compartment Features | ||||
| Black Leather Adjustable Driver and Passenger Seats | STD | |||
| Swivel Bases for Driver and Passenger Seats | STD | |||
| Heated Driver and Passenger Seats | STD | |||
| Leather Wrapped Heated Steering Wheel with Integrated Controls | STD | |||
| Keyless Start | STD | |||
| Windshield with Filter Band | STD | |||
| Rain Sensor for Windshield Wipers | STD | |||
| Automatic LED Headlights | STD | |||
| Emergency Call System | STD | |||
| Smartphone Integration For Apple Carplay® and Android™ Auto | STD | |||
| Mercedes-Benz® MBUX Multimedia System with 10.25” Touchscreen | STD | |||
| 360 Degree Backup Cameras | STD | |||
| Ceiling Mounted Speakers | STD | |||
| Tray for Smartphones with Charging Ports | STD | |||
| Intelligent Navigation | STD | |||
| Auxiliary Start Switch | STD | |||
| Powered Windows | STD | |||
| Door-mounted Driver and Passenger Assist Handles | STD | |||
| Powered Door Locks | STD | |||
| Vinyl Floor Covering | STD | |||
| Driver, Passenger, and Windshield Thermal Barrier Shades | STD | |||
| Instrument Cluster with Color Display | STD | |||
| Dinette and Living Area | ||||
| Driver Side | ||||
| L-Shaped Dinette (Converts To Bed)11 | STD | |||
| Convertible Jack Knife Sofa Bed | OPT | |||
| 11Piece of furniture sleeps one comfortably. | ||||
| Kitchen | ||||
| Kitchen Features | ||||
| Stainless Steel Microwave/Air Fryer | STD | |||
| Dometic 10.5cu ft Dual-Hinge Refrigerator | STD | |||
| Single-Burner Portable Induction Stove | STD | |||
| Stainless Steel Sink w/Hide-away faucet | STD | |||
| Galley Overhead Cabinets | STD | |||
| Task Lighting | STD | |||
| Solid Surface Galley Countertop w/Countertop Extension | STD | |||
| Bedroom | ||||
| Bedroom Features | ||||
| Rear Dual Twin Beds - Converts to King12 | STD | |||
| LED Reading Lights | STD | |||
| Overhead Cabinets | STD | |||
| CPAP Outlet & Passthrough | STD | |||
| His & Hers Clothes Cabinets13 | STD | |||
| 12Size= 75.625" x 80.25" | ||||
| 13Large cabinets that are easily accessible when bed has been converted to king mattress | ||||
| Bathroom | ||||
| Bathroom Features | ||||
| 48x32 Full Residential-Style Wet Bath | STD | |||
| Large Shower Skylight | STD | |||
| Towel and Toilet Paper Holders | STD | |||
| Roof Vent Fan | STD | |||
| Oversized Mirror With Hidden Medicine Cabinet | STD | |||
| Large Black Aluminum Under-Sink Cabinet w/GFCI Outlet | STD | |||
