Row Labels | 32 FA | 32 SA | 34 PA | 36 LA | 36 UA | Footnotes | BYO |
Weights and Measures | |||||||
Dimensions | |||||||
Overall Length (approx.) | 34' 3" | 34' 3" | 36' 1" | 37' 6" | 38' | The approximated coach width and length does not include side-view mirrors or ladders. | |
Wheel Base | 228” | 228" | 252" | 252" | 252" | ||
Overall Width | 101" | 101" | 101" | 101" | 101" | The approximated coach width and length does not include side-view mirrors or ladders. | |
Overall Height | 12' 10" | 12' 10" | 12' 10" | 12' 10" | 12' 10" | ||
Minimum Garage Height | 14' | 14' | 14' | 14' | 14' | ||
Interior Height | 84" | 84" | 84" | 84" | 84" | ||
Interior Width | 96" | 96" | 96" | 96" | 96" | ||
Square Footage (approx.) | 315 | 300 | 355 | 330 | 355 | Square footage was calculated with the slide-outs fully extended. | |
Basement Storage (cubic feet, approx.) | 140 | 140 | 203 | 203 | 203 | ||
Weight Limits | |||||||
GAWR-Front (pounds) | 9000 | 9000 | 9000 | 9000 | 9000 | ||
GAWR-Rear (pounds) | 15500 | 15500 | 17500 | 17500 | 17500 | ||
GVWR (pounds) | 24000 | 24000 | 26000 | 26000 | 26000 | ||
Maximum Trailer Weight (pounds) | 5000 | 5000 | 4000 | 5000 | 4000 | Maximum Trailer Weight is dependent on the loading and towing variables which include the GVWR, GAWR and GCWR, as well as adequate trailer brakes. | |
Hitch Rating (pounds) | 5000 | 5000 | 5000 | 5000 | 5000 | ||
GCWR (pounds) | 30000 | 30000 | 30000 | 30000 | 30000 | ||
Capacities | |||||||
Fuel Tank (gallons) | 80 | 80 | 80 | 80 | 80 | ||
Fresh Water (gallons) | 70 | 70 | 70 | 70 | 70 | ||
Grey Water (gallons) | 66 | 66 | 66 | 66 | 66 | ||
Black Water (gallons) | 50 | 50 | 50 | 50 | 50 | ||
LPG Tank (gallons) | 20.3 | 20.3 | 20.3 | 20.3 | 20.3 | LPG tank can only be filled to 80% capacity. | |
Quantities | |||||||
Number of Slideouts | 2 | 2 | 4 | 2 | 2 | ||
Sleeping Capacity | 5 to 7 | 4 to 6 | 3 to 6 | 4 to 6 | 5 to 7 | Dependent on furniture and dinette options. | |
Sleeping Areas | 4 to 6 | 2 to 4 | 2 to 4 | 2 to 4 | 4 to 6 | Dependent on furniture and dinette options. | |
Seat Belts | 4 to 6 | 5 to 7 | 5 to 7 | 5 to 7 | 4 to 6 | Dependent on furniture and dinette options. | |
Seating Capacity | 6 to 8 | 7 to 9 | 7 to 9 | 8 to 10 | 6 to 8 | Dependent on furniture and dinette options. | |
Chassis and Drivetrain | |||||||
Chassis and Drivetrain Features | |||||||
Ford® F-53 Super Duty® Class A Motorhome Chassis | STD | STD | STD | STD | STD | ||
Ford® V8 7.3L 350 HP Gas Engine with 468 lb-ft Torque | STD | STD | STD | STD | STD | Peak horsepower achieved at 3,900 RPM. Peak torque achieved at 3,900 RPM. | |
Two-wheel Drive | STD | STD | STD | STD | STD | ||
210-Amp Alternator | STD | STD | STD | STD | STD | ||
TorqShift® 6-speed Automatic Overdrive with Tow/Haul Mode | STD | STD | STD | STD | STD | ||
Aluminum Wheels | STD | STD | STD | STD | STD | ||
Front and Rear 255/80R 22.5 Tires | STD | STD | STD | STD | STD | ||
(1) 12-Volt Flooded Lead-Acid Chassis Batteries | STD | STD | STD | STD | STD | ||
Hydraulic Leveling Jacks with Control Panel | STD | STD | STD | STD | STD | ||
Rear Sway Bar | STD | STD | STD | STD | STD | ||
Custom Tuned Sachs® Shock Absorbers | STD | STD | STD | STD | STD | ||
Front Radiator | STD | STD | STD | STD | STD | ||
Front and Rear Disc Brakes | STD | STD | STD | STD | STD | ||
Manual Parking Brake | STD | STD | STD | STD | STD | ||
Rear Fuel Fill | STD | STD | STD | STD | STD | ||
Automatic Traction Control | STD | STD | STD | STD | STD | ||
Cruise Control | STD | STD | STD | STD | STD | ||
Suspension | |||||||
Front and Rear Tapered Multi-leaf Suspension | STD | STD | STD | STD | STD | ||
Construction | |||||||
Construction Features | |||||||
Seamless One-piece Gel-coat Fiberglass Molded Roof Cap | STD | STD | STD | STD | STD | ||
5 1/4" Formed Roof Insulation | STD | STD | STD | STD | STD | ||
Tubular Aluminum Roof Skeleton Frames | STD | STD | STD | STD | STD | ||
Extraordinaire™ Ducted Air Cooling System | STD | STD | STD | STD | STD | ||
One-piece Molded Gel-coat Fiberglass Front and Rear Caps | STD | STD | STD | STD | STD | ||
Crane® Composites Noble® Select All-Composite Exterior Sidewalls | STD | STD | STD | STD | STD | ||
Tubular Aluminum Wall Skeleton Frames | STD | STD | STD | STD | STD | ||
High-performance Thermal Insulation in Sidewalls | STD | STD | STD | STD | STD | ||
Steel Floor Skeleton | STD | STD | STD | STD | STD | ||
Engineered Wood Sub-flooring | STD | STD | STD | STD | STD | ||
1 1/2" Thick Thermal Insulation in Floor | STD | STD | STD | STD | STD | ||
Steel Basement Construction | STD | STD | STD | STD | STD | ||
Rust Protective Undercoating | STD | STD | STD | STD | STD | ||
Hydraulic Slide-out Mechanisms | STD | STD | STD | STD | STD | ||
Electrical | |||||||
Electrical Features | |||||||
Liquid Propane (LP) Coach | STD | STD | STD | STD | STD | Propane is used to power the ducted furnaces, the water heater, and the liquid propane cooktop. | |
Spyder Controls Multiplex System | STD | STD | STD | STD | STD | ||
Firefly Integrations Mira Module | STD | STD | STD | STD | STD | Download the accompanying Vegatouch app to control your coach locally within Bluetooth range. | |
Centralized 7.5” Spyder System Main Monitor | STD | STD | STD | STD | STD | ||
Interior Entryway Spyder System Color Touchscreen | STD | STD | STD | STD | STD | ||
Conveniently Located Spyder Switch Panels Throughout Coach | STD | STD | STD | STD | STD | ||
2,000-Watt Pure Sine Wave Inverter Charger with Auto-Gen Start and Interior Remote Control | STD | STD | STD | STD | STD | Automatic generator start capabilities controlled through Spyder Controls Multiplex System. | |
(4) 6-Volt, 230-Amp Hours Flooded Lead-Acid House Batteries | STD | STD | STD | STD | STD | ||
50-Amp Shore Power | STD | STD | STD | STD | STD | ||
Auxiliary Solar Port | STD | STD | STD | STD | STD | ||
HD Over-the-air Antenna | STD | STD | STD | STD | STD | ||
Park Cable and Ground Satellite Hook-up | STD | STD | STD | STD | STD | ||
Prep for In-motion Satellite | STD | STD | STD | STD | STD | ||
Blu-ray™ Player | STD | STD | STD | STD | STD | ||
Satellite Receiver | STD | STD | STD | STD | STD | Requires subscription. (Only available with in-motion satellite option) | |
Prep for Wi-Fi Booster | STD | STD | STD | STD | STD | ||
12-Volt Breaker Panel | STD | STD | STD | STD | STD | ||
12-Volt Disconnect Switch | STD | STD | STD | STD | STD | ||
Rotary Disconnect Switches for House Batteries, Chassis Batteries, and Inverter | STD | STD | STD | STD | STD | ||
Ground Fault Circuit Interrupter (GFCI) Outlets at Galley, Lavatories, and Sewer Bay | STD | STD | STD | STD | STD | ||
110-Volt Exterior Receptacle | STD | STD | STD | STD | STD | ||
Surge Guard® Transfer Switch | STD | STD | STD | STD | STD | ||
USB Receptacles Throughout Coach | STD | STD | STD | STD | STD | ||
Generators and Power Systems | |||||||
5.5-Kilowatt Onan® Quiet Gas Generator | STD | STD | STD | - | - | Generators and Power Systems (SELECT ONE) | |
7.0-Kilowatt Onan® Quiet Gas Generator | OPT | OPT | OPT | STD | STD | Generators and Power Systems (SELECT ONE) | |
Battery Slide-out Tray | STD | STD | STD | - | STD | Due to 36 LA's batteries being located under the entry steps, they do not get a slide tray. | |
Air Conditioning | |||||||
(2) 13,500-BTU Air Conditioners | STD | STD | STD | STD | STD | Air Conditioning (SELECT ONE) | |
(1) 13,500-BTU Air Conditioner and (1) 15,000-BTU Air Conditioner with Heat Pump | DEP(OPT) | DEP(OPT) | DEP(OPT) | OPT | OPT | Option only available with 7.0-Kilowatt Onan® Quiet Gas Generator. 15,000-BTU air conditioner replaces the front 13,500-BTU air conditioner. Only the 15,000-BTU air conditioner has a heat pump. | Air Conditioning (SELECT ONE) |
Space Heating | |||||||
(1) 35,000-BTU and (1) 30,000-BTU Ducted Furnaces | STD | - | - | - | - | ||
(1) 35,000-BTU Ducted Furnace | - | STD | - | - | - | ||
(1) 35,000-BTU and (1) 20,000-BTU Ducted Furnaces | - | - | STD | - | - | ||
(1) 30,000-BTU and (1) 20,000-BTU Ducted Furnaces | - | - | - | STD | STD | ||
Solar Panels | |||||||
Prep for Solar Panels | OPT | OPT | OPT | OPT | OPT | Includes docking ports for aftermarket solar panels. | Solar Panels |
(1) 200-Watt Solar Panel with (1) 30-Amp Controller | OPT | OPT | OPT | OPT | OPT | Solar Panels | |
(2) 200-Watt Solar Panels with (1) 30-Amp Controller | OPT | OPT | OPT | OPT | OPT | Solar Panels | |
Electrical Add On Options | |||||||
In-motion Satellite Dish | OPT | OPT | OPT | OPT | OPT | In-motion Satellite Dish and Prewiring for Winegard® Trav’ler™ Satellite cannot be optioned together on 32 FA, 32 SA, or 34 PA. High-definition programming is not available on a domed satellite antenna unless you subscribe to DISH Network®. | Electrical Add On Options |
Prewiring for Winegard® Trav’ler™ Satellite | OPT | OPT | OPT | OPT | OPT | In-motion Satellite Dish and Prewiring for Winegard® Trav’ler™ Satellite cannot be optioned together on 32 FA, 32 SA, or 34 PA. | Electrical Add On Options |
Wi-Fi Booster | OPT | OPT | OPT | OPT | OPT | Electrical Add On Options | |
Starlink Prep in Sewer Compartment | OPT | OPT | OPT | OPT | OPT | Electrical Add On Options | |
Plumbing | |||||||
Plumbing Features | |||||||
Truma AquaGo™ Comfort Instant Water Heater | STD | STD | STD | STD | STD | Controllable through the Truma control panel and the Spyder System control panels. | |
Water Heater Bypass System | STD | STD | STD | STD | STD | ||
Aqua View Showermiser™ | STD | STD | STD | STD | STD | ||
Water Filter | STD | STD | STD | STD | STD | ||
Water Pump Switch Access from Spyder System and Sewer Bay Board | STD | STD | STD | STD | STD | ||
Low-point Water Drain Lines | STD | STD | STD | STD | STD | ||
Black Holding Tank Flush System | STD | STD | STD | STD | STD | ||
Gravity Water Fill | STD | STD | STD | STD | STD | ||
Heated Fresh and Holding Tank Compartment via Heat Duct | STD | STD | STD | STD | STD | ||
Tank Level Monitor System | STD | STD | STD | STD | STD | ||
Centralized Exterior Sewer Bay with Gravity Black and Grey Evacuation Ports | STD | STD | STD | STD | STD | ||
Exterior Rinse Hose with Shower Head | STD | STD | STD | STD | STD | ||
Sewer Bay Hand Sanitizer and Paper Towel Holders | STD | STD | STD | STD | STD | ||
Exterior | |||||||
Exterior Features | |||||||
Full-body Paint with (3) Layers of Clear Coat | STD | STD | STD | STD | STD | ||
Single-colored Slide-out Endwalls | STD | STD | STD | STD | STD | ||
High Performance Protective Film on Front Cap and Select Areas | STD | STD | STD | STD | STD | ||
(1) Girard® Side-mounted Powered Patio Awning with Integrated LED Lighting | STD | STD | STD | STD | STD | ||
Girard® Slide-out Toppers | STD | STD | STD | STD | STD | ||
Side-swinging Exterior Storage Doors with Gas Shocks | STD | STD | STD | STD | STD | ||
Lockable Handles on Compartment Doors | STD | STD | STD | STD | STD | ||
Motion-sensor Lights in Cargo Bay | STD | STD | STD | STD | STD | ||
120-Volt and 12-Volt Outlets Inside Cargo Bays | STD | STD | STD | STD | STD | ||
GatorHyde-lined Cargo Walls and Floor | STD | STD | STD | STD | STD | ||
Frameless, Single-Pane Windows | STD | STD | STD | STD | STD | ||
Exterior Patio Light | STD | STD | STD | STD | STD | ||
Daytime Running Lights | STD | STD | STD | STD | STD | ||
Chrome Power Heated Side-View Mirrors with Integrated Cameras | STD | STD | STD | STD | STD | ||
Exterior TV with Soundbar | STD | STD | STD | STD | STD | ||
Fast Charge USB ports within Exterior TV Compartment | STD | STD | STD | STD | STD | ||
Lightweight Entry Door with Integrated Screen | STD | STD | STD | STD | STD | ||
Entry Door Grab Handle | STD | STD | STD | STD | STD | ||
Deadbolt Front Entrance Lock | STD | STD | STD | STD | STD | ||
Automatic Double Entry Step | STD | STD | STD | STD | STD | ||
Mud Flaps | STD | STD | STD | STD | STD | ||
Lippert™ On-The-Go™ Telescoping Ladder | STD | STD | STD | STD | STD | All units will ship with a Lippert™ On-The-Go™ Prepped Receiver installed. | |
Paint Schemes | |||||||
Generation 10 Paint Scheme | OPT | OPT | OPT | OPT | OPT | ||
Generation 11 Paint Scheme | OPT | OPT | OPT | OPT | OPT | ||
Paint Color Options | |||||||
Crimson Mist Full Body Paint | OPT | OPT | OPT | OPT | OPT | ||
Nasa Full Body Paint | OPT | OPT | OPT | OPT | OPT | ||
White Mahogany Full Body Paint | OPT | OPT | OPT | OPT | OPT | ||
Frosted Granite Full Body Paint | OPT | OPT | OPT | OPT | OPT | ||
Interior | |||||||
Interior Features | |||||||
Handcrafted Overhead Cabinetry | STD | STD | STD | STD | STD | ||
Carpeted Step Well with Composite Steps | STD | STD | STD | STD | STD | ||
Living Area TV | STD | STD | STD | STD | STD | Moved to new location above dinette on 32 FA. Removes section of overhead cabinetry on 32 FA. | |
Solid Surface Galley Countertop | STD | STD | STD | STD | STD | ||
Handcrafted Slide-out Fascia | STD | STD | STD | STD | STD | ||
Soft Touch Vinyl Ceiling | STD | STD | STD | STD | STD | ||
Dimmable LED Lighting | STD | STD | STD | STD | STD | ||
Carbon Monoxide Detector | STD | STD | STD | STD | STD | ||
LPG Leak Detector | STD | STD | STD | STD | STD | ||
Smoke Detector | STD | STD | STD | STD | STD | ||
Fire Extinguisher | STD | STD | STD | STD | STD | ||
Solar and Privacy Shades | STD | STD | STD | STD | STD | ||
Soft-closing Drawers | STD | STD | STD | STD | STD | ||
Powered Roof Vents | STD | STD | STD | STD | STD | ||
Interior Grab Handle at Entry Door | STD | STD | STD | STD | STD | ||
Egress Windows Throughout Coach | STD | STD | STD | STD | STD | ||
Interior Décor Packages | |||||||
Moondance | OPT | OPT | OPT | OPT | OPT | ||
Iron Mountain | OPT | OPT | OPT | OPT | OPT | ||
Upholstery Fabrics | |||||||
Snowhill Sand Furniture Coverings and Montage Alpaca Driver and Passenger Seats | DEP | DEP | DEP | DEP | DEP | Always paired with Moondance Fabric Suite. | |
Snowhill Dove Furniture Coverings and Montage Landscape Driver and Passenger Seats | DEP | DEP | DEP | DEP | DEP | Always paired with Iron Mountain Fabric Suite. | |
Cabinetry Color | |||||||
Sandstone | OPT | OPT | OPT | OPT | OPT | Always paired with Montano Flooring | |
White Linen | OPT | OPT | OPT | OPT | OPT | Always paired with Sea Grass Flooring | |
Flooring | |||||||
Monteano Luxury Vinyl | OPT | OPT | OPT | OPT | OPT | Always paired with Sandstone Cabinets | |
Sea Grass Luxury Vinyl | OPT | OPT | OPT | OPT | OPT | Always paired with White Linen Cabinets | |
Interior Add On Options | |||||||
Storage Compartment Within Entry Steps | STD | STD | STD | - | STD | 36 LA's batteries are located under entry steps. | Interior Add On Options (SELECT ONE) |
Recessed Step Well Lighting | - | STD | STD | STD | STD | Interior Add On Options (SELECT ONE) | |
Standalone Living Area Fireplace | - | OPT | OPT | OPT | OPT | Interior Add On Options (SELECT ONE) | |
Central Vacuum System | OPT | OPT | OPT | OPT | OPT | Interior Add On Options (SELECT ONE) | |
Washer & Dryer | |||||||
Prep for Washer and Dryer | - | STD | STD | STD | STD | Washer & Dryer (SELECT ONE) | |
Combo Washer-Dryer | - | OPT | - | - | - | Washer & Dryer (SELECT ONE) | |
Stacked Washer and Dryer | - | - | OPT | OPT | OPT | Washer & Dryer (SELECT ONE) | |
Driver's Compartment | |||||||
Driver's Compartment Features | |||||||
Montage Power Driver and Passenger Seats | STD | STD | STD | STD | STD | ||
Dual Driver And Passenger Seat Armrests | STD | STD | STD | STD | STD | ||
Swivel Bases for Driver and Passenger Seats | STD | STD | STD | STD | STD | ||
Adjustable Seatbelt Brackets | STD | STD | STD | STD | STD | ||
Tilt and Telescoping Steering Wheel with Integrated Controls | STD | STD | STD | STD | STD | ||
Ergonomic Dash with Graphite Accents | STD | STD | STD | STD | STD | ||
Mounted Dash Fans | STD | STD | STD | STD | STD | ||
Cupholders on Driver and Passenger Side | STD | STD | STD | STD | STD | ||
Backlit Instrument Cluster | STD | STD | STD | STD | STD | ||
Center Storage Compartments | STD | STD | STD | STD | STD | ||
Generator Start & Stop Rocker Switch | STD | STD | STD | STD | STD | ||
USB Dash Receptacles | STD | STD | STD | STD | STD | ||
12-Volt Dash Receptacle | STD | STD | STD | STD | STD | ||
Backlit Dash Rocker Switches | STD | STD | STD | STD | STD | ||
Retractable Lap Desk | STD | STD | STD | STD | STD | ||
Passenger Console Controls for Map Light and Fan | STD | STD | STD | STD | STD | ||
Driver and Passenger Map Lights | STD | STD | STD | STD | STD | ||
One-piece Panoramic Windshield | STD | STD | STD | STD | STD | ||
Single-motor Intermittent Windshield Wipers | STD | STD | STD | STD | STD | ||
Automatic LED Headlights | STD | STD | STD | STD | STD | ||
Side-view Cameras | STD | STD | STD | STD | STD | Integrated within side-view mirrors and activated by turn signals. | |
Color Back-up Camera | STD | STD | STD | STD | STD | ||
7" High Definition LED Multichannel Monitor for Side-view and Back-up Cameras | STD | STD | STD | STD | STD | ||
Stereo with AM & FM Radio, CD Player, and Satellite Radio | STD | STD | STD | STD | STD | Subscription required for satellite radio. | |
Ceiling Mounted Speakers | STD | STD | STD | STD | STD | ||
Overhead Cabinetry with Honeycomb-patterned Glass | STD | STD | STD | STD | STD | ||
Auxiliary Start Switch | STD | STD | STD | STD | STD | ||
Concealed Electric Horn | STD | STD | STD | STD | STD | ||
Manual, Horizontal Opening Driver and Passenger Side Windows | STD | STD | STD | STD | STD | ||
Powered Solar and Privacy Windshield Shade | STD | STD | STD | STD | STD | ||
Driver's Compartment Add On Options | |||||||
Passenger Seat Footrest | OPT | OPT | OPT | OPT | OPT | Driver's Compartment Add On Options | |
In-dash Navigation System | OPT | OPT | OPT | OPT | OPT | RoadTrippers mobile app required to connect to RV navigation system. | Driver's Compartment Add On Options |
Front Overhead TV | OPT | OPT | OPT | OPT | OPT | Driver's Compartment Add On Options | |
Electric Front Overhead Drop-Down Bunk | OPT | OPT | OPT | OPT | OPT | Mattress measures 72" x 30". Decreases overhead storage capacity. Maximum weight limit of drop-down bunk is 250 pounds. Now includes telescoping ladder. | Driver's Compartment Add On Options |
Dinette and Living Area | |||||||
Driver Side Dinette | |||||||
72" Booth Dinette-Sleeper | STD | STD | - | - | STD | Piece of furniture converts to 69" x 45" sleeping area. | Driver Side Dinette (SELECT ONE) |
72" Dinette with Chairs | OPT | OPT | - | - | OPT | Formerly known as "Dinette Computer Workstation". The printer bump-out was removed for more leg room. The keyboard and printer trays have been converted to a drawer and a fixed shelf to maximize storage. Includes (2) freestanding accent chairs and (2) wooden folding chairs. | Driver Side Dinette (SELECT ONE) |
72" Dinette Bar | OPT | - | - | - | - | Includes (2) freestanding accent chairs and (2) wooden folding chairs. | Driver Side Dinette (SELECT ONE) |
72" Booth Dinette-Sleeper and Recliner | - | - | - | STD | - | Piece of furniture converts to 69" x 45" sleeping area. | Driver Side Dinette (SELECT ONE) |
72" Dinette with Chairs and Recliner | - | - | - | OPT | - | Formerly known as "Dinette Computer Workstation". The printer bump-out was removed for more leg room. The keyboard and printer trays have been converted to a drawer and a fixed shelf to maximize storage. Includes (2) freestanding accent chairs and (2) wooden folding chairs. | Driver Side Dinette (SELECT ONE) |
96" U-Shaped Dinette-Sleeper | - | - | - | OPT | - | Piece of furniture converts to 46" x 88" sleeping area. | Driver Side Dinette (SELECT ONE) |
Driver Side Furniture | |||||||
89" Flip and Fold Sofa Bed | - | STD | - | STD | - | Piece of furniture converts to 74" x 70" sleeping area. | Driver Side Furniture (SELECT ONE) |
89" Air Coil Sofa Bed | - | OPT | - | OPT | - | Mattress measures 72" x 59" and requires external pump. | Driver Side Furniture (SELECT ONE) |
95" Flip and Fold Sofa Bed | - | - | STD | - | - | Piece of furniture converts to 80" x 70" sleeping area. | Driver Side Furniture (SELECT ONE) |
95" Air Coil Sofa Bed | - | - | OPT | - | - | Mattress measures 72" x 59" and requires external pump. | Driver Side Furniture (SELECT ONE) |
95" Super Sofa | - | - | OPT | - | - | Consists of a flip and fold sofa bed, a 27" single theater seat, and a center console. Flip and fold sofa bed converts to 70" X 51" sleeping area. | Driver Side Furniture (SELECT ONE) |
66" Flip and Fold Sofa Bed | - | - | - | - | STD | Piece of furniture converts to 51" x 70" sleeping area. | Driver Side Furniture (SELECT ONE) |
66" Air Coil Sofa Bed | - | - | - | - | OPT | Mattress measures 72" x 52" and requires external pump. | Driver Side Furniture (SELECT ONE) |
66" Theatre Seating | - | - | - | - | OPT | Driver Side Furniture (SELECT ONE) | |
89" Theatre Seating | - | OPT | - | - | - | Driver Side Furniture (SELECT ONE) | |
95" Theatre Seating | - | - | OPT | - | - | Driver Side Furniture (SELECT ONE) | |
Driver Side Bunk Beds (28" x 70") | STD | - | - | - | STD | Now includes tablet holders in each bunk. | Driver Side Furniture (SELECT ONE) |
Passenger Side Dinette | Driver Side Furniture (SELECT ONE) | ||||||
72" Dinette Bar with Lift TV | - | - | STD | - | - | Includes (2) freestanding accent chairs and (2) wooden folding chairs. Lift TV deletes cabinetry over dinette. | Driver Side Furniture (SELECT ONE) |
72" Dinette with Chairs | - | - | OPT | - | - | Formerly known as "Dinette Computer Workstation". The printer bump-out was removed for more leg room. The keyboard and printer trays have been converted to a drawer and a fixed shelf to maximize storage. Includes (2) freestanding accent chairs and (2) wooden folding chairs. | Driver Side Furniture (SELECT ONE) |
72" Booth Dinette-Sleeper | - | - | OPT | - | - | Piece of furniture converts to 69" x 45" sleeping area. | Driver Side Furniture (SELECT ONE) |
Passenger Side Furniture | |||||||
66" Flip and Fold Sofa Bed | STD | - | - | - | - | Piece of furniture converts to 51" x 70" sleeping area. | Passenger Side Furniture (SELECT ONE) |
66" Theatre Seating | OPT | - | - | - | - | Passenger Side Furniture (SELECT ONE) | |
Kitchen | |||||||
Kitchen Features | |||||||
1.7-Cubic Foot Smart Convection Microwave with Air Fry | STD | STD | STD | STD | STD | ||
Double Bowl Kitchen Sink with Single Lever Faucet and Pull-down Sprayer | STD | STD | STD | STD | STD | ||
Galley Overhead Cabinets | STD | STD | STD | STD | STD | ||
Panoramic Galley Window | STD | STD | STD | STD | STD | ||
Task Lighting | STD | STD | STD | STD | STD | ||
Full Tile Backsplash | STD | STD | STD | STD | STD | ||
Solid Surface Galley Countertop, Sink, and Cooktop Cover | STD | STD | STD | STD | STD | ||
Refrigerator Options | |||||||
20-Cubic Foot Stainless Steel Residential Refrigerator with Top Freezer | STD | STD | - | STD | STD | Refrigerator volume is approximated. | |
23-Cubic Foot Stainless Steel Residential Refrigerator with French Doors and Bottom Freezer | - | - | STD | - | - | Refrigerator volume is approximated. | |
Cooking Appliances | |||||||
Three-Burner Liquid Propane Cooktop | STD | STD | STD | STD | STD | Cooking Appliances (SELECT ONE) | |
Oven Range with Liquid Propane Cooktop | OPT | OPT | OPT | OPT | OPT | Cooking Appliances (SELECT ONE) | |
Bedroom | |||||||
Bedroom Features | |||||||
Overhead Cabinets | STD | STD | STD | STD | STD | ||
Under Bed Storage | STD | STD | STD | STD | STD | ||
Bedside Windows | STD | STD | STD | STD | STD | ||
Bed Comforter with Throw Pillows | STD | STD | STD | STD | STD | ||
Handcrafted Privacy Door | STD | STD | STD | STD | STD | ||
LED Reading Lights | STD | STD | STD | STD | STD | ||
Nightstand with Solid Surface Tops | STD | STD | STD | STD | STD | ||
Mounted Bedroom TV | STD | STD | STD | STD | STD | ||
Centralized Entertainment Center | STD | STD | STD | STD | STD | Houses Blu-ray™ player, satellite receiver, and cable TV hook-up. | |
Wardrobe with Drawers Underneath | STD | STD | STD | STD | STD | ||
Laundry Hamper | STD | STD | STD | STD | STD | ||
Mattress Options | |||||||
Memory Foam King Mattress (72" x 80") | STD | STD | OPT | - | STD | Mattress Options (SELECT ONE) | |
Memory Foam Queen Mattress (60" x 80") | OPT | OPT | STD | STD | OPT | Mattress Options (SELECT ONE) | |
Bed Slide Options | |||||||
Mounted Headboard | STD | - | STD | STD | - | ||
Window at Head of Bed | - | STD | - | - | STD | ||
Bedroom Add On Options | |||||||
Ceiling Fan | OPT | OPT | OPT | OPT | OPT | Bedroom Add On Options | |
Bathroom | |||||||
Bathroom Features | |||||||
(1) Porcelain Master Bathroom Sink | STD | STD | STD | STD | STD | ||
Solid Surface Lavatory Top | STD | STD | STD | STD | STD | ||
Handheld Shower Head with Slide Bar | STD | STD | STD | STD | STD | ||
Shower Skylight | STD | STD | STD | STD | STD | ||
Shower LED Light with Sliding Cover | STD | STD | STD | STD | STD | ||
Towel and Toilet Paper Holders | STD | STD | STD | STD | STD | ||
Mirrored Medicine Cabinet | STD | STD | STD | STD | STD | ||
Roof Vent Fan | STD | STD | STD | STD | STD | ||
Base Cabinet | STD | STD | STD | STD | STD | ||
Number of Bathrooms | |||||||
(1) Bathroom | STD | STD | STD | - | - | ||
(1) Bathroom and (1) Half-bath | - | - | - | STD | STD | All half-baths contain a toilet and a solid surface countertop with a single porcelain sink. | |
Shower | |||||||
One-Piece Molded Fiberglass Shower (34.5" x 34.5") | STD | - | - | - | - | ||
One-Piece Molded Fiberglass Shower (28.5" x 40.5") | - | STD | STD | STD | STD | ||
Toilet | |||||||
(1) Gravity Flush Toilet | STD | STD | STD | - | - | ||
(1) Gravity Flush Toilet and (1) Macerator Toilet | - | - | - | STD | STD |
