Row Labels | 33 AA | 37 BA | 38 KA | Footnotes | BYO |
Weights and Measures | |||||
Dimensions | |||||
Overall Length (approx.) | 35' 2" | 38' 6" | 39' 6" | The approximated coach width and length does not include side-view mirrors or ladders. | |
Wheel Base | 198" | 234" | 252" | ||
Overall Width | 101" | 101" | 101" | The approximated coach width and length does not include side-view mirrors or ladders. | |
Overall Height | 12' 10" | 12' 10" | 12' 10" | ||
Minimum Garage Height | 14' | 14' | 14' | ||
Interior Height | 84" | 84" | 84" | ||
Interior Width | 96" | 96" | 96" | ||
Square Footage (approx.) | 335 | 375 | 390 | Square footage was calculated with the slide-outs fully extended. | |
Basement Storage (cubic feet, approx.) | 84 | 119 | 119 | ||
Weight Limits | |||||
GAWR-Front (pounds) | 14320 | 14320 | 14320 | ||
GAWR-Rear (pounds) | 24000 | 24000 | 24000 | ||
GVWR (pounds) | 38320 | 38320 | 38320 | ||
Maximum Trailer Weight (pounds) | 10000 | 10000 | 10000 | Maximum trailer weight is dependent on the loading and towing variables which include the GVWR, GAWR, and GCWR, as well as adequate trailer brakes. | |
Hitch Rating (pounds) | 10000 | 10000 | 10000 | ||
GCWR (pounds) | 48320 | 48320 | 48320 | ||
Capacities | |||||
Fuel Tank (gallons) | 100 | 100 | 100 | ||
DEF Tank (gallons) | 13 | 13 | 13 | Diesel Exhaust Fluid (DEF) is the active component used in Selective Catalytic Reduction (SCR) engines to reduce nitrogen oxide emissions by 90% to meet EPA standards. | |
Fresh Water (gallons) | 90 | 90 | 90 | ||
Grey Water (gallons) | 70 | 70 | 70 | ||
Black Water (gallons) | 50 | 50 | 50 | ||
LPG Tank (gallons) | 36 | 36 | 36 | LPG tank can only be filled to 80% capacity. | |
Quantities | |||||
Number of Slideouts | 4 | 3 | 3 | ||
Sleeping Capacity | 4 to 6 | 2 to 6 | 4 to 8 | Dependent on furniture and dinette options. | |
Sleeping Areas | 2 to 4 | 1 to 5 | 3 to 6 | Dependent on furniture and dinette options. | |
Seat Belts | 5 to 7 | 4 to 8 | 4 to 7 | Dependent on furniture and dinette options. | |
Seating Capacity | 7 to 10 | 7 to 10 | 6 to 9 | Dependent on furniture and dinette options. | |
Chassis and Drivetrain | |||||
Chassis and Drivetrain Features | |||||
Freightliner® XCM Modular Rail Rear Engine Diesel Chassis | STD | STD | STD | ||
Cummins® L9 380 HP Diesel Engine with 1,150 lb-ft Torque | STD | STD | STD | Peak horsepower achieved at 2,200 RPM. Peak torque achieved at 1,200 RPM. Cummins® B6.7 360 HP Diesel Engine is no longer available. | |
160-Amp Alternator | STD | STD | STD | ||
Allison® 3000 MH 6-speed Automatic Transmission with Lock-up Torque Converter | STD | STD | STD | ||
Aluminum Wheels | STD | STD | STD | ||
Front and Rear 295/80R 22.5 Tires | STD | STD | STD | ||
(2) 12-Volt Flooded Lead-Acid Chassis Batteries | STD | STD | STD | ||
Hydraulic Leveling Jacks with Control Panel | STD | STD | STD | ||
Freightliner® V-Series VFS I-beam Front Suspension | STD | STD | STD | ||
Freightliner® V-Series V-Ride Rear Suspension | STD | STD | STD | ||
Custom Tuned Sachs® Shock Absorbers | STD | STD | STD | ||
Rear Radiator | STD | STD | STD | ||
Front Disc Brakes and Rear Drum Brakes | STD | STD | STD | ||
Full Air Brake System with Automatic Slack Adjusters | STD | STD | STD | ||
Single Stage Variable Geometry Turbocharger (VGT) Engine Brake | STD | STD | STD | ||
Manual Parking Brake | STD | STD | STD | ||
Driver and Passenger Side Fuel Fill | STD | STD | STD | ||
Tire Pressure Monitoring | STD | STD | STD | ||
Adaptive Cruise Control | STD | STD | STD | ||
Automatic Traction Control | STD | STD | STD | ||
Collision Mitigation with Forward Warning and Active Braking | STD | STD | STD | ||
Electronic Stability Control | STD | STD | STD | ||
Construction | |||||
Construction Features | |||||
Seamless One-piece Gel-coat Fiberglass Molded Roof Cap | STD | STD | STD | ||
5 1/4" Formed Roof Insulation | STD | STD | STD | ||
Tubular Aluminum Roof Skeleton Frames | STD | STD | STD | ||
Extraordinaire™ Ducted Air Cooling System | STD | STD | STD | ||
One-piece Molded Gel-coat Fiberglass Front and Rear Caps | STD | STD | STD | ||
Steel Cockpit Overhead Support Frame | STD | STD | STD | ||
Crane® Composites Noble® Select All-Composite Exterior Sidewalls | STD | STD | STD | ||
Tubular Aluminum Wall Skeleton Frames | STD | STD | STD | ||
High-performance Thermal Insulation in Sidewalls | STD | STD | STD | ||
Steel Floor Skeleton | STD | STD | STD | ||
Engineered Wood Sub-flooring | STD | STD | STD | ||
1 1/2" Thick Thermal Insulation in Floor | STD | STD | STD | ||
Steel Basement Construction | STD | STD | STD | ||
Rust Protective Undercoating | STD | STD | STD | ||
Slide-out Mechanisms | |||||
Combination Hydraulic and Electric Slide-out Mechanisms | STD | - | - | The 33 AA's vanity slide features a electrically powered rack and pinion system. | |
Hydraulic Slide-out Mechanisms | - | STD | STD | ||
Electrical | |||||
Electrical Features | |||||
Spyder Controls Multiplex System | STD | STD | STD | ||
Firefly Integrations Mira Module | STD | STD | STD | Download the accompanying Vegatouch app to control your coach locally within Bluetooth range. | |
Centralized 7.5” Spyder System Main Monitor | STD | STD | STD | ||
Interior Entryway Spyder System Color Touchscreen | STD | STD | STD | ||
Additional Spyder Color Touchscreens Throughout Coach | STD | STD | STD | ||
8.0-Kilowatt Onan® Quiet Diesel Generator | STD | STD | STD | ||
Generator Slide Tray | STD | STD | STD | ||
2,000-Watt Pure Sine Wave Inverter Charger with Auto-Gen Start and Interior Remote Control | STD | STD | STD | Automatic generator start capabilities controlled through Spyder Controls Multiplex System. | |
Battery Slide-out Tray | STD | STD | STD | ||
50-Amp Shore Power | STD | STD | STD | ||
Auxiliary Solar Port | STD | STD | STD | ||
HD Over-the-air Antenna | STD | STD | STD | ||
Park Cable and Ground Satellite Hook-up | STD | STD | STD | ||
Prep for In-motion Satellite | STD | STD | STD | ||
Blu-ray™ Player | STD | STD | STD | ||
Satellite Receiver | STD | STD | STD | Requires subscription. (Only available with in-motion satellite option.) | |
12-Volt Breaker Panel | STD | STD | STD | ||
12-Volt Disconnect Switch | STD | STD | STD | ||
Rotary Disconnect Switches for House Batteries, Chassis Batteries, and Inverter | STD | STD | STD | ||
Ground Fault Circuit Interrupter (GFCI) Outlets at Galley, Lavatories, and Sewer Bay | STD | STD | STD | ||
110-Volt Exterior Receptacle | STD | STD | STD | ||
Surge Guard® Transfer Switch | STD | STD | STD | ||
USB Receptacles Throughout Coach | STD | STD | STD | ||
Heating and Cooktop Power Source | |||||
Liquid Propane (LP) Coach | STD | STD | STD | Propane is used to power the ducted furnaces, the water heater, and the liquid propane cooktop. | Heating and Cooktop Power Source (SELECT ONE) |
Hydronic Heating & Electronic Appliance Equipped Coach | OPT | OPT | OPT | Replaces the ducted furnaces, the Truma AquaGo™ water heater, and the liquid propane cooktop with an Aqua-Hot® heat exchanger and induction cooktops. Removes LPG tank. Formerly known as "All-Electric Coach". | Heating and Cooktop Power Source (SELECT ONE) |
House Batteries | |||||
(6) 6-Volt, 230-Amp Hours Flooded Lead-Acid House Batteries | STD | STD | STD | House Batteries (SELECT ONE) | |
(6) 6-Volt, 210-Amp Hours Extended Cycle AGM House Batteries | OPT | OPT | OPT | House Batteries (SELECT ONE) | |
Air Conditioning | |||||
(2) 15,000-BTU Air Conditioners with Heat Pumps | STD | STD | STD | Air Conditioning (SELECT ONE) | |
(2) 15,000-BTU Low Profile Air Conditioners with Heat Pumps and Condensation Drains | OPT | OPT | OPT | Air Conditioning (SELECT ONE) | |
Space Heating | |||||
(1) 35,000-BTU and (1) 30,000-BTU Ducted Furnaces | DEP | - | - | Standard with LP coach option. | |
(1) 30,000-BTU and (1) 20,000-BTU Ducted Furnaces | - | DEP | - | Standard with LP coach option. | |
(2) 30,000-BTU Ducted Furnaces | - | - | DEP | Standard with LP coach option. | |
Aqua-Hot® 250D Heat Exchanger | DEP | DEP | DEP | Replaces ducted furnaces when hydronic heating & electronic appliance equipped coach option is selected. Aqua-Hot® heat exchanger provides both heated air and water. | |
Solar Panels | |||||
Prep for Solar Panels | OPT | OPT | OPT | Includes docking ports for aftermarket solar panels. | Solar Panels |
(1) 200-Watt Solar Panel with (1) 30-Amp Controller | OPT | OPT | OPT | Solar Panels | |
(3) 200-Watt Solar Panels with (1) 30-Amp Controller | OPT | OPT | OPT | Solar Panels | |
Electrical Add On Options | |||||
In-motion Satellite Dish | OPT | OPT | OPT | High-definition programming is not available on a domed satellite antenna unless you subscribe to DISH Network®. In-motion satellite dish and prewiring for Winegard® Trav’ler™ satellite cannot be optioned together on the 33 AA. | Electrical Add On Options |
Prewiring for Winegard® Trav’ler™ Satellite | OPT | OPT | OPT | In-motion satellite dish and prewiring for Winegard® Trav’ler™ satellite cannot be optioned together on the 33 AA. | Electrical Add On Options |
Wi-Fi Booster | OPT | OPT | OPT | Electrical Add On Options | |
Starlink Prep in Sewer Compartment | OPT | OPT | OPT | Electrical Add On Options | |
Plumbing | |||||
Plumbing Features | |||||
Aqua View Showermiser™ | STD | STD | STD | ||
Water Filter | STD | STD | STD | ||
Water Pump Switch Access from Spyder System and Sewer Bay Board | STD | STD | STD | ||
Low-point Water Drain Lines | STD | STD | STD | ||
Black Holding Tank Flush System | STD | STD | STD | ||
Gravity Water Fill | STD | STD | STD | ||
Heated Fresh and Holding Tank Compartment via Heat Duct | STD | STD | STD | ||
Tank Level Monitor System | STD | STD | STD | ||
Centralized Exterior Sewer Bay with Gravity Black and Grey Evacuation Ports | STD | STD | STD | ||
Exterior Rinse Hose with Shower Head | STD | STD | STD | ||
Sewer Bay Hand Sanitizer and Paper Towel Holders | STD | STD | STD | ||
Water Heater | |||||
Truma AquaGo™ Comfort Instant Water Heater | DEP | DEP | DEP | Now controllable through the Truma control panel and the Spyder System control panels. Standard with LP coach option. | |
Aqua-Hot® 250D Heat Exchanger | DEP | DEP | DEP | Replaces Truma AquaGo™ Comfort instant water heater when hydronic heating & electronic appliance equipped coach option is selected. Aqua-Hot® heat exchanger provides both heated air and water. | |
Water Heater Bypass System | DEP | DEP | DEP | Standard with LP coach option. Not necessary with hydronic heating & electronic appliance equipped coach option. | |
Exterior | |||||
Exterior Features | |||||
Full-body Paint with (3) Layers of Clear Coat | STD | STD | STD | ||
Single-colored Slide-out Endwalls | STD | STD | STD | ||
High Performance Protective Film on Front Cap and Select Areas | STD | STD | STD | ||
(1) Girard® Side-mounted Powered Patio Awning with Integrated LED Lighting | STD | STD | STD | ||
Girard® Powered Door Awning with Integrated LED Lighting | STD | STD | STD | ||
Girard® Slide-out Toppers | STD | STD | STD | ||
Side-swinging Exterior Storage Doors with Gas Shocks | STD | STD | STD | ||
Lockable Handles on Compartment Doors | STD | STD | STD | ||
Motion-sensor Lights in Cargo Bay | STD | STD | STD | ||
120-Volt and 12-Volt Outlets Inside Cargo Bays | STD | STD | STD | ||
Pass-through Basement Storage | STD | STD | STD | ||
Charcoal Carpet Cargo Walls | STD | STD | STD | ||
Fiberglass Reinforced Plastic Basement Floor | STD | STD | STD | ||
Frameless, Single-Pane Windows | STD | STD | STD | ||
Exterior Patio Light | STD | STD | STD | ||
Daytime Running Lights | STD | STD | STD | ||
Docking Lights | STD | STD | STD | ||
Chrome Power Heated Side-View Mirrors with Integrated Cameras | STD | STD | STD | ||
Exterior TV with Soundbar | STD | STD | STD | ||
Fast Charge USB ports within Exterior TV Compartment | STD | STD | STD | ||
Lightweight Entry Door with Integrated Screen | STD | STD | STD | ||
Entry Door Grab Handle | STD | STD | STD | ||
Deadbolt Front Entrance Lock | STD | STD | STD | ||
Automatic Double Entry Step | STD | STD | STD | ||
Front Door Entry System via Key Fob | STD | STD | STD | Entry system does not include exterior Spyder keypad. | |
Mud Flaps | STD | STD | STD | ||
Custom Rock Guard | STD | STD | STD | ||
Lippert™ On-The-Go™ Telescoping Ladder | STD | STD | STD | All units will ship with a Lippert™ On-The-Go™ Prepped Receiver installed. | |
Exterior Add On Options | |||||
(1) Manual Storage Compartment Slide-out Tray | OPT | OPT | OPT | Trays slide out on both sides of motorhome. | Exterior Add On Options |
Paint Scheme Options | |||||
Generation 5 Exterior Paint Scheme | OPT | OPT | OPT | ||
Generation 6 Exterior Paint Scheme | OPT | OPT | OPT | ||
Paint Color Options | |||||
Euro Blue Full Body Paint | OPT | OPT | OPT | ||
Frosted Granite Full Body Paint | OPT | OPT | OPT | ||
Bordeaux Full Body Paint | OPT | OPT | OPT | ||
Nasa Full Body Paint | OPT | OPT | OPT | ||
Interior | |||||
Interior Features | |||||
Handcrafted Overhead Cabinetry | STD | STD | STD | ||
Carpeted Step Well with Composite Steps | STD | STD | STD | ||
Powered Step Well Cover | STD | STD | STD | ||
Living Area TV | STD | STD | STD | ||
Solid Surface Galley Countertop | STD | STD | STD | ||
Handcrafted Slide-out Fascia | STD | STD | STD | ||
Soft Touch Vinyl Ceiling | STD | STD | STD | ||
Dimmable LED Lighting | STD | STD | STD | ||
Prep for Washer and Dryer | STD | STD | STD | ||
Carbon Monoxide Detector | STD | STD | STD | ||
LPG Leak Detector | STD | STD | STD | ||
Smoke Detector | STD | STD | STD | ||
Fire Extinguisher | STD | STD | STD | ||
Solar and Privacy Shades | STD | STD | STD | ||
Soft-closing Drawers | STD | STD | STD | ||
Powered Roof Vents | STD | STD | STD | ||
Interior Grab Handle at Entry Door | STD | STD | STD | ||
Egress Windows Throughout Coach | STD | STD | STD | ||
Interior Décor Packages | |||||
Stoney Creek | OPT | OPT | OPT | ||
Solstice | OPT | OPT | OPT | ||
Upholstery Fabrics | |||||
Montage Landscape | DEP | DEP | DEP | Always paired with Stoney Creek Fabric Suite. | |
Montage Alpaca | DEP | DEP | DEP | Always paired with Solstice Fabric Suite. | |
Cabinetry Color | |||||
Sandstone | OPT | OPT | OPT | ||
White Linen | OPT | OPT | OPT | ||
Platinum | OPT | OPT | OPT | ||
Floor Tiles | |||||
Marble Obsess Porcelain Tile (Gloss) | OPT | OPT | OPT | Floor Tiles (SELECT ONE) | |
Marble Obsess Porcelain Tile (Matte) | OPT | OPT | OPT | Floor Tiles (SELECT ONE) | |
Interior Add On Options | |||||
Standalone Living Area Fireplace | OPT | - | OPT | Interior Add On Options | |
Stacked Washer and Dryer | OPT | OPT | OPT | Interior Add On Options | |
Gold Heat® Dual Zones Heated Tile Floor | OPT | OPT | OPT | Interior Add On Options | |
Central Vacuum System | OPT | OPT | OPT | Interior Add On Options | |
Driver's Compartment | |||||
Driver's Compartment Features | |||||
Montage Power Driver and Passenger Seats | STD | STD | STD | ||
Dual Driver And Passenger Seat Armrests | STD | STD | STD | ||
Swivel Bases for Driver and Passenger Seats | STD | STD | STD | ||
Adjustable Seatbelt Brackets | STD | STD | STD | ||
Powered Passenger Seat Footrest | STD | STD | STD | ||
Tilt and Telescoping Steering Wheel with Integrated Controls | STD | STD | STD | ||
Adjustable Accelerator and Brake Pedals | STD | STD | STD | ||
Wraparound Dash with Matte Gray Accents | STD | STD | STD | ||
Mounted Dash Fans | STD | STD | STD | ||
Cupholders on Driver and Passenger Side | STD | STD | STD | ||
Digital Dash Cluster | STD | STD | STD | ||
(1) Center Storage Drawer | STD | STD | STD | ||
Generator Start & Stop Rocker Switch | STD | STD | STD | ||
USB Dash Receptacles | STD | STD | STD | ||
12-Volt Dash Receptacle | STD | STD | STD | ||
Backlit Dash Rocker Switches | STD | STD | STD | ||
Passenger Console Controls for Map Light, Fan, and Step Well Cover | STD | STD | STD | ||
Driver and Passenger Map Lights | STD | STD | STD | ||
One-piece Panoramic Windshield | STD | STD | STD | ||
Single-motor Intermittent Windshield Wipers | STD | STD | STD | ||
Automatic LED Headlights | STD | STD | STD | ||
Side-view Cameras | STD | STD | STD | Integrated within side-view mirrors and activated by turn signals. | |
Color Back-up Camera | STD | STD | STD | ||
7" High Definition LED Multichannel Monitor for Side-view and Back-up Cameras | STD | STD | STD | ||
Stereo with AM & FM Radio, CD Player, and Satellite Radio | STD | STD | STD | Subscription required for satellite radio. | |
Ceiling Mounted Speakers | STD | STD | STD | ||
Overhead Cabinetry with Wooden Panel Doors | STD | STD | STD | ||
Auxiliary Start Switch | STD | STD | STD | ||
Concealed Air Horn | STD | STD | STD | ||
Manual Opening Driver Side Window | STD | STD | STD | ||
Solid, Non-opening Passenger Side Window | STD | STD | STD | ||
Powered Solar and Privacy Windshield Shade | STD | STD | STD | ||
Manual Solar and Privacy Shades on Side Windows | STD | STD | STD | ||
Driver's Compartment Options | |||||
In-dash Navigation System | OPT | OPT | OPT | RoadTrippers mobile app required to connect to RV navigation system. | Driver's Compartment Options |
Front Overhead TV | OPT | OPT | OPT | Driver's Compartment Options | |
Electric Front Overhead Drop-Down Bunk | OPT | OPT | OPT | Mattress measures 72" x 30". Decreases overhead storage capacity. Maximum weight limit of drop-down bunk is 250 pounds. Now includes telescoping ladder. | Driver's Compartment Options |
Dinette and Living Area | |||||
Driver Side Dinette | |||||
75" Booth Dinette-Sleeper | - | STD | - | Piece of furniture converts to 72" x 45" sleeping area. | Driver Side Dinette (SELECT ONE) |
75" Dinette with Chairs | - | OPT | - | Formerly known as "Dinette Computer Workstation". The printer bump-out was removed for more leg room. The keyboard and printer trays have been converted to a drawer and a fixed shelf to maximize storage. Includes (2) freestanding accent chairs and (2) wooden folding chairs. | Driver Side Dinette (SELECT ONE) |
75" U-shaped Dinette | - | OPT | - | Driver Side Dinette (SELECT ONE) | |
72" Booth Dinette-Sleeper | - | - | STD | Piece of furniture converts to 69" x 45" sleeping area. | Driver Side Dinette (SELECT ONE) |
72" Dinette with Chairs | - | - | OPT | Formerly known as "Dinette Computer Workstation". The printer bump-out was removed for more leg room. The keyboard and printer trays have been converted to a drawer and a fixed shelf to maximize storage. Includes (2) freestanding accent chairs and (2) wooden folding chairs. | Driver Side Dinette (SELECT ONE) |
72" U-shaped Dinette | - | - | OPT | Driver Side Dinette (SELECT ONE) | |
Driver Side Furniture | |||||
85" Air Coil Sofa Bed with Recliner | STD | - | - | Mattress measures 72" x 59" and includes internal pump. | Driver Side Furniture (SELECT ONE) |
114" Super Sofa | OPT | - | - | Consists of a flip and fold sofa bed, a 37" single theater seat, and a center console. Flip and fold sofa bed converts to 70" x 59" sleeping area. | Driver Side Furniture (SELECT ONE) |
74" Air Coil Sofa Bed | - | STD | - | Mattress measures 72" x 52" and includes internal pump. | Driver Side Furniture (SELECT ONE) |
74" Theater Seating | - | OPT | - | Driver Side Furniture (SELECT ONE) | |
85" Air Coil Sofa Bed | - | - | STD | Mattress measures 72" x 59" and includes internal pump. | Driver Side Furniture (SELECT ONE) |
83" Theater Seating | OPT | - | OPT | Driver Side Furniture (SELECT ONE) | |
Passenger Side Dinette | |||||
72" Booth Dinette-Sleeper | STD | - | - | Piece of furniture converts to 69" x 45" sleeping area. | Passenger Side Dinette (SELECT ONE) |
72" Dinette Bar with Lift TV | OPT | - | - | Includes (2) freestanding accent chairs and (2) wooden folding chairs. Lift TV deletes cabinetry over dinette. | Passenger Side Dinette (SELECT ONE) |
72" Dinette with Chairs | OPT | - | - | Formerly known as "Dinette Computer Workstation". The printer bump-out was removed for more leg room. The keyboard and printer trays have been converted to a drawer and a fixed shelf to maximize storage. Includes (2) freestanding accent chairs and (2) wooden folding chairs. | Passenger Side Dinette (SELECT ONE) |
72" U-shaped Dinette | OPT | - | - | Passenger Side Dinette (SELECT ONE) | |
Passenger Side Furniture | |||||
64" DE Sofa Bed with Lift TV | - | STD | - | Piece of furniture converts to 57" x 49" sleeping area. Lift TV deletes cabinetry over furniture. | Passenger Side Furniture (SELECT ONE) |
Recliner and Lift TV with Fireplace | - | OPT | - | Lift TV deletes cabinetry over furniture. | Passenger Side Furniture (SELECT ONE) |
Passenger Side Bunk Beds (28" x 70") | - | - | STD | Now includes tablet holders in bunk areas. | Passenger Side Furniture (SELECT ONE) |
Telescoping Ladder for Bunk Beds | - | - | DEP | Included with Drop-Down Bunk Option | |
Kitchen | |||||
Kitchen Features | |||||
1.7-Cubic Foot Smart Convection Microwave with Air Fry | STD | STD | STD | ||
Double Bowl Kitchen Sink with Single Lever Faucet and Pull-down Sprayer | STD | STD | STD | ||
Galley Overhead Cabinets | STD | STD | STD | ||
Panoramic Galley Window | STD | STD | STD | ||
Task Lighting | STD | STD | STD | ||
Full Tile Backsplash | STD | STD | STD | ||
Solid Surface Galley Countertop, Sink, and Cooktop Cover | STD | STD | STD | ||
Refrigerator Options | |||||
20-Cubic Foot Stainless Steel Residential Refrigerator with Top Freezer | STD | STD | - | Refrigerator volume is approximated. | |
23-Cubic Foot Stainless Steel Residential Refrigerator with French Doors and Bottom Freezer | - | - | STD | Refrigerator volume is approximated. | |
Cooking Appliances | |||||
Three-Burner Liquid Propane Cooktop | DEP(STD) | DEP(STD) | DEP(STD) | Standard with LP coach option. Not available with hydronic heating & electronic appliance equipped coach option. | Cooking Appliances |
Oven Range with Liquid Propane Cooktop | DEP(OPT) | DEP(OPT) | DEP(OPT) | Option with LP coach option. Replaces three-burner liquid propane cooktop when selected. Not available with hydronic heating & electronic appliance equipped coach option. Cannot option dishwasher and oven with cooktop together. | Cooking Appliances |
Two-Burner Induction Cooktop | DEP | DEP | DEP | Replaces three-burner liquid propane cooktop when hydronic heating & electronic appliance equipped coach option is selected. | |
Drawer-style Dishwasher | OPT | OPT | OPT | Cannot option dishwasher and oven with cooktop together. | Cooking Appliances |
Extendable Countertops | |||||
Flip and Fold Countertop Extension | STD | - | - | ||
Manual Release Expand-An-Island | - | STD | STD | ||
Bedroom | |||||
Bedroom Features | |||||
Under Bed Storage | STD | STD | STD | ||
Bedside Windows | STD | STD | STD | ||
Overhead Cabinets with Headboard | STD | STD | STD | ||
Bed Comforter with Throw Pillows | STD | STD | STD | ||
Handcrafted Privacy Door | STD | STD | STD | ||
LED Reading Lights | STD | STD | STD | ||
Nightstand with Solid Surface Tops | STD | STD | STD | ||
Mounted Bedroom TV | STD | STD | STD | ||
Centralized Entertainment Center | STD | STD | STD | Houses Blu-ray™ player, satellite receiver, and cable TV hook-up. | |
Ceiling Fan | STD | STD | STD | ||
Laundry Hamper | STD | STD | STD | ||
Mattress Options | |||||
Memory Foam King Mattress (72" x 80") | STD | STD | STD | Mattress Options (SELECT ONE) | |
Memory Foam Queen Mattress (60" x 80") | - | OPT | OPT | Mattress Options (SELECT ONE) | |
Bedroom Storage | |||||
Floor-to-ceiling Closet Space | STD | - | - | ||
Wardrobe with Drawers Underneath | - | STD | STD | ||
Bedroom Add On Options | |||||
Bedroom Egress Door | OPT | OPT | OPT | Bedroom Add On Options | |
Bathroom | |||||
Bathroom Features | |||||
(1) Porcelain Master Bathroom Sink | STD | STD | STD | ||
Solid Surface Lavatory Top | STD | STD | STD | ||
Handheld Shower Head with Slide Bar | STD | STD | STD | ||
Shower Skylight | STD | STD | STD | ||
Shower LED Light with Sliding Cover | STD | STD | STD | ||
Towel and Toilet Paper Holders | STD | STD | STD | ||
Mirrored Medicine Cabinet | STD | STD | STD | ||
Roof Vent Fan | STD | STD | STD | ||
Base Cabinet | STD | STD | STD | ||
Number of Bathrooms | |||||
(1) Bathroom | STD | - | - | ||
(1) Bathroom and (1) Half-bath | - | STD | STD | All half-baths contain a toilet and a solid surface countertop with a single porcelain sink. | |
Shower | |||||
One-Piece Molded Fiberglass Shower (34.5" x 34.5") | STD | - | - | ||
One-Piece Molded Fiberglass Shower (28.5" x 40.5") | - | STD | STD | ||
Toilet | |||||
(1) Gravity Flush Toilet | STD | - | - | ||
(1) Gravity Flush Toilet and (1) Macerator Toilet | - | STD | STD |
