Midas Specifications
Close Specs
Midas
Select multiple floor plans to compare.
| 24 RT | 24 MT | Midas Footnotes | ||
| Weights and Measures | ||||
| Dimensions | ||||
| Overall Length (approx.) | 25' 4" | 25' 4" | ||
| Overall Width | 90" | 90" | ||
| Overall Height | 10' 6" | 10' 6" | ||
| Interior Height | 78" | 78" | ||
| Interior Width | 87" | 87" | ||
| Wheel Base | 156" | 156" | ||
| Weight Limits | ||||
| GVWR (pounds) | 11000 | 11000 | ||
| Hitch Rating (pounds) | 2000 | 2000 | ||
| GCWR (pounds) | 13000 | 13000 | ||
| Capacities | ||||
| Fuel Tank (gallons) | 31 | 31 | ||
| Fresh Water (gallons) | 30 | 38 | ||
| Grey Water (gallons) | 28 | 23 | ||
| Black Water (gallons) | 26 | 22 | ||
| LPG Tank (gallons) | 12.2 | 12.2 | ||
| Chassis and Drivetrain | ||||
| Chassis and Drivetrain Features | ||||
| Ford® 350 HD AWD Transit Cutaway Chassis | STD | STD | ||
| All-wheel Drive | STD | STD | ||
| Ford® 3.5-Liter EcoBoost® 310 HP Gas Engine with 400 lb-ft Torque 1 | STD | STD | Peak horsepower achieved at 5,000 RPM. Peak torque achieved at 2,500 RPM. | |
| 210-Amp Alternator | STD | STD | ||
| Ford® 10-Speed Selectshift® Automatic Transmission with Overdrive | STD | STD | ||
| Aluminum Wheels | STD | STD | ||
| Front and Rear 205/75R 16C Tires | STD | STD | ||
| (1) 12-Volt Flooded Lead-Acid Chassis Batteries | STD | STD | ||
| Front Radiator | STD | STD | ||
| Four Wheel ABS Brakes | STD | STD | ||
| Manual Parking Brake | STD | STD | ||
| Tire Pressure Monitoring | STD | STD | ||
| Post-collision Braking | STD | STD | ||
| Forward Collision Warning | STD | STD | ||
| Lane Keeping System | STD | STD | ||
| Pre-Collision Assist with Automatic Emergency Braking (AEB) | STD | STD | ||
| Adaptive Cruise Control | STD | STD | ||
| Electric Power Assisted Steering (EPAS) | STD | STD | ||
| Construction | ||||
| Construction Features | ||||
| Seamless One-piece Gel-coat Fiberglass Molded Roof Cap | STD | STD | ||
| One-piece Molded Gel-coat Fiberglass Front and Rear Caps | STD | STD | ||
| Electrical | ||||
| Electrical Features | ||||
| Liquid Propane (LP) Coach 2 | STD | STD | Propane is used to power the ducted furnaces, the water heater, and the liquid propane cooktop. | |
| Spyder Controls Multiplex System | STD | STD | ||
| 4.0-Kilowatt Onan® Gas Generator | STD | STD | ||
| 2,000-Watt Pure Sine Wave Inverter | STD | STD | ||
| (2) 12-Volt Flooded Lead-Acid House Batteries | STD | STD | ||
| Wall-mounted Thermostat with Built-in Temperature Sensor | STD | STD | ||
| (1) 15,000-BTU Air Conditioner | STD | STD | ||
| (1) 20,000-BTU Ducted Furnace | STD | STD | ||
| SmartPlug® Detachable 30-Amp Shore Power Cord | STD | STD | ||
| Prep for Satellite | STD | STD | ||
| (1) Solar Panel | STD | STD | ||
| HD Over-the-air Antenna | STD | STD | ||
| Park Cable Hook-up | STD | STD | ||
| 12-Volt Breaker Panel | STD | STD | ||
| 12-Volt Disconnect Switch | STD | STD | ||
| Strategically Placed 110-Volt Outlets | STD | STD | ||
| 110-Volt Exterior Receptacle | STD | STD | ||
| Surge Guard® Transfer Switch | STD | STD | ||
| USB Receptacles Throughout Coach | STD | STD | ||
| Plumbing | ||||
| Plumbing Features | ||||
| Truma AquaGo™ Comfort Plus Instant Water Heater | STD | STD | ||
| Water Heater Bypass System | STD | STD | ||
| Aqua View Showermiser™ | STD | STD | ||
| Water Filter | STD | STD | ||
| Water Pump | STD | STD | ||
| Low-point Water Drain Lines | STD | STD | ||
| Black Holding Tank Flush System | STD | STD | ||
| Gravity Water Fill | STD | STD | ||
| Heated Water and Holding Tanks | STD | STD | ||
| Tank Level Monitor System | STD | STD | ||
| Centralized Exterior Sewer Bay with Gravity Black and Grey Evacuation Ports | STD | STD | ||
| Exterior Rinse Hose with Shower Head | STD | STD | ||
| Fresh Water Hookup for City Water and Tank Fill | STD | STD | ||
| Sewer Hose Storage | STD | STD | ||
| Exterior | ||||
| Exterior Features | ||||
| Full-body Paint with (3) Layers of Clear Coat | STD | STD | ||
| High Performance Protective Film on Front Cap, Front Cab, and Other Select Areas | STD | STD | ||
| (1) Girard® Side-mounted Powered Patio Awning with Integrated LED Lighting | STD | STD | ||
| Large Rear Access Storage | STD | - | ||
| Lockable Handles on Compartment Doors | STD | STD | ||
| Motion-sensor Lights in Cargo Bay | STD | STD | ||
| Flush-Style Tinted Windows with Tip-out Feature | STD | STD | ||
| Exterior Patio Light | STD | STD | ||
| Fog Lights | STD | STD | ||
| Heated, Electrically Adjustable Side-view Mirrors | STD | STD | ||
| Electric Single Entrance Step | STD | STD | ||
| Rear Mud Guards | STD | STD | ||
| Exterior Color Package Options | ||||
| Dovetail | OPT | OPT | ||
| Iceberg | OPT | OPT | ||
| Midnight | OPT | OPT | ||
| Palladian | OPT | OPT | ||
| Interior | ||||
| Interior Features | ||||
| Handcrafted Cabinetry | STD | STD | ||
| (1) Flat-panel Television | - | STD | ||
| (2) Flat-panel Televisions | STD | - | ||
| Solid Surface Galley Countertop | STD | STD | ||
| LED Lighting | STD | STD | ||
| Accent Lighting in Lounge, Galley, and Bedroom | STD | STD | ||
| Carbon Monoxide Detector | STD | STD | ||
| LPG Leak Detector | STD | STD | ||
| Smoke Detector | STD | STD | ||
| Fire Extinguisher | STD | STD | ||
| Privacy Shades | STD | STD | ||
| Soft-closing Drawer Slides | STD | STD | ||
| Powered Roof Vents | STD | STD | ||
| Interior Grab Handle at Entry Door | STD | STD | ||
| Treated Fabric Suites Options | ||||
| Champagne | OPT | OPT | ||
| Mink | OPT | OPT | ||
| Cabinetry Stain Options | ||||
| Linen | OPT | OPT | ||
| Shadow | OPT | OPT | ||
| Sandstone | OPT | OPT | ||
| Ultraleathers Options | ||||
| Etna Linen 3 | OPT | OPT | Must be paired with Champagne Fabric Suite. | |
| Seaport Bamboo 4 | OPT | OPT | Must be paired with Mink Fabric Suite. | |
| Driver's Compartment | ||||
| Driver's Compartment Features | ||||
| Adjustable Driver and Passenger Seats | STD | STD | ||
| Backlit Instrument Cluster with Message Center | STD | STD | ||
| Center Stack Console with Integrated Shifter | STD | STD | ||
| Rain Sensor for Windshield Wipers | STD | STD | ||
| Automatic High-beam Headlamps | STD | STD | ||
| Automatic LED Headlights | STD | STD | ||
| 3-point Safety Belts | STD | STD | ||
| Driver and Passenger Air Bags | STD | STD | ||
| SOS Post-Crash Alert System™ 5 | STD | STD | The SOS Post-Crash Alert System™ causes the headlights to flash and the horn to beep once any air bag inside the coach deploys. | |
| Safety Canopy™ Side-Curtain Airbags | STD | STD | ||
| Colored Multi-Function Touch Screen AM/FM Stereo with SYNC® 3, Bluetooth, Navigation, and Dual USB Ports | STD | STD | ||
| Smartphone Integration For Apple Carplay® and Android™ Auto | STD | STD | ||
| Color Back-up Camera with Monitor | STD | STD | ||
| Overhead Storage | STD | STD | ||
| A-pillar Assist Handles | STD | STD | ||
| Vinyl Floor Covering | STD | STD | ||
| Kitchen | ||||
| Kitchen Features | ||||
| Stainless Steel Convection Microwave | STD | STD | ||
| One-Burner Induction Cooktop | STD | STD | ||
| Stainless Steel Single Bowl Sink and Faucet with Built-in Sprayer | STD | STD | ||
| Galley Overhead Cabinets | STD | STD | ||
| Solid Surface Galley Countertop | STD | STD | ||
| Refrigerator Options | ||||
| Gas-Electric, 5.5-Cubic Foot Refrigerator | STD | - | ||
| Gas-Electric, 7.0-Cubic Foot Refrigerator | - | STD | ||
| 12-Volt, 8.0-Cubic Foot Refrigerator | - | OPT | ||
| Bedroom | ||||
| Bedroom Features | ||||
| Queen-sized Murphy Bed (60" x 74") with Sofa | - | STD | ||
| (2) Twin Mattresses (32" x 76") with Capability to Convert into King Bed (86" x 76") | STD | - | ||
| Under Bed Storage | STD | - | ||
| Mounted Flat-panel TV | STD | STD | ||
| Overhead Cabinet | STD | STD | ||
| Bathroom | ||||
| Bathroom Features | ||||
| (1) Bathroom | STD | STD | ||
| Porcelain Vessel Sink with Chrome Faucet | STD | - | ||
| Undermount Porcelain Sink with Chrome Faucet | - | STD | ||
| Solid Surface Lavatory Top | STD | STD | ||
| 24" x 36" Shower with Built-in Caddy and Retractable Shower Screen | STD | - | ||
| 34" x 34" Corner Shower with Sliding Glass Door | - | STD | ||
| Shower Skylight | STD | STD | ||
| Towel and Toilet Paper Holders | STD | STD | ||
| Overhead Medicine Cabinet | STD | - | ||
| Roof Vent Fan | STD | STD | ||
| Base Cabinet | STD | STD |
