How To Winterize Your Tiffin Motorhome

Tiffin MotorhomesTiffin Tips
Placeholder ImageWinterize New
Winterizing your motorhome is a crucial part of ensuring RV reliability. To be sure you complete each important step, follow our checklist.

The autumn leaves have begun to fall. Winter is coming. And that means it's time to start preparing your motorhome for hibernation if you plan on parking it for a long period of time. Winterizing is one of the most important parts of ensuring that your coach runs smoothly for many years to come.

“Customers need to winterize their motorhomes in frigid weather to keep water from freezing and damaging the expensive parts in their plumbing system," said D. Ray Hester, the Tiffin Service Center Shop Manager. “When pipes freeze and expand, then thaw out, tiny leaks or cracks can occur, which could ultimately cause water damage to the interior of the motorhome."

Below is the detailed checklist you need to be sure you don't forget an important step in winterizing your motorhome. We also have a video tutorial that will show you how to winterize your RV — check it out for a visual guide.

Before you start winterizing, be sure to have these items on hand:

  • 1-1/16-inch wrench or socket and ratchet
  • Water pressure regulator valve
  • RV antifreeze
  • Standard half-inch hose to connect to the inlet side of the water pump
  • Teflon tape

Find Your Sewer/Utilities Bay And Prepare to Drain

Dumping Your Black and Grey Holding Tanks

Dump your black and grey holding tanks before you dump your fresh water holding tank. Remember: It is important to dump black and grey tanks in a proper dump site or station!

  1. Locate your campsite's sewer inlet, or find your nearest sewer dump station.
  2. Locate your Tiffin's sewer/utilities bay, and open that bay's cargo door.
  3. With the cargo door open, you will see an access hole at the bottom of this compartment. Open the access hole, and feed your sewer hose through it.
  4. Connect the sewer hose to your Tiffin's unitized outlet valve for your black and grey tanks. Make sure the valve cover is removed before attempting to attach the sewer hose!
  5. BEFORE ATTEMPTING TO OPEN THE BLACK OR GREY HOLDING TANK VALVES, attach the other end of the sewer hose to the designated sewer inlet or dump station located in step 1.
  6. Dump your black tank first.
  7. After dumping the black tank, attach a water hose — one that is different than the one you use for your fresh water — to the flush valve, and let the water run at full force for at least 10 minutes to ensure your black tank is completely flushed. You can then close the blank tank valve and disconnect this hose afterward.
  8. Dump the grey tank to help flush out anything left in your sewer hose from the black tank.
  9. Once completed, ensure both grey and black holding tank valves are closed, and disconnect the sewer hose completely.

Dumping Your Fresh Water Holding Tan
k and Water Lines

  1. At your sewer/utilities bay, open the fresh water tank valve located at the bottom of this bay. The water will run freely onto the ground. (This is okay because it's fresh water!)
  2. Also in the sewer/utilities bay, locate the service panel containing your water lines. Drain the hot and cold water lines, and then shut them off.
  3. Release the pressure from the water tank filter, and remove the filter by unscrewing it from the base. Once the filter is off and water is drained from the canister, reinstall the filter.
  4. Drain the hot water heater by removing the service panel cover. BE SURE THE TANK IS SWITCHED OFF. (You can also turn off the hot water heater breaker to kill power to the water heater outside.) Relieve the pressure, and remove the plug, which will require a 1-1/16-inch wrench. It's common for the anode rod to be rotted, so be prepared if you need to replace it. Once the plug is removed, water will drain freely.
  5. Finally, locate the outside service panel containing the refrigerator water line. The hose should be hanging from the top, just outside the panel. Drain the fridge water from the outside of the coach by using a wrench to loosen the bolt on the end of the line and turning the water on to allow the remaining water to run out.

But Wait, There's More To Drain

Placeholder Image3
  1. Now that you've emptied all the tanks and outside lines, it's time to test all faucets to check that both hot and cold water are no longer flowing.
  2. Drain toilets; then flush.
  3. Go to the shower and test that hot and cold water has drained.
  4. Run the washing machine and dishwasher to ensure they are also drained.
  5. And finally, return to the outside service panel containing your city water fill. This is usually the same outside panel containing the grey and black tanks. Have a regulator on hand that is pre-set between 40-50 pounds of air. Anything more could cause damage to faucets and lines. Hook your regulator up to the city water fill, and connect it to the water heater. Water will run freely.
  6. Then, wrap Teflon tape around the base of the anode rod and install it into the water heater. Start by turning it by hand before using your wrench to avoid cross-threading. Tighten the rod back up with a wrench and reinstall the protective plate.

Don't Forget to Drain the Refrigerator

Placeholder Image4
  1. To drain the water dispenser of the refrigerator, one person will need to be inside at the fridge to press the water dispenser down, and one person will need to be outside to hook up the air hose to the water line. Once the hose is pushing air through, all remaining water will run free from the water dispenser, so be ready with a large cup.
  2. Next, remove the water filter out of the fridge.
  3. Install a plug (which came with your coach) where the filter was located, and close it up.
  4. Now you can reconnect the water line to the fridge, and turn the valve back to an open position.

Last Steps: Add Antifreeze

Placeholder Image5
  1. To be able to safely add antifreeze to each water source throughout the coach, first, bypass the water heater. Do this by turning the lever to “bypass" so that antifreeze will not run through the water heater. This is a very important step.
  2. Now attach your common air hose to the city water gauge, so that air pressure will run through all your appliances' water lines. Return inside to flush out all hot and cold water from faucets by letting them run dry.
  3. Go back outside and take the pressure you have connected to the city water gauge back off.
  4. Install the antifreeze via the inlet side of the water pump, usually identifiable by the clear plastic screen. Do so by disconnecting the inlet side and attaching a half-inch clear hose, then place it into the antifreeze. This hose comes with standard packages in a Tiffin motorhome, but you can also purchase it at your local hardware store or from the Tiffin parts department.
  5. Turn on the water pump, and turn the faucet back on. You will see the antifreeze run through the faucet by turning on both hot and cold water. The same applies to the dishwasher and washing machine. Don't forget about the outside faucet or shower.
  6. Leave faucets open, meaning leave them in a position as if they would be running. The antifreeze will eventually run dry.
  7. Pour antifreeze into all sink drains and clean off remnants from the sink bowl. Then pour it into toilets, allowing it to remain there for the season. Repeat the same with your showers.
  8. Then pour it into toilets, allowing it to remain there for the season.
  9. Repeat the same with your showers.

NOTE: It's important to remember that there are many types of motorhomes, and because of that, these steps may vary from brand to brand. This checklist was based on a Tiffin motorhome.
